Schneider Electric NSYSMPSE8 Side entry rails for the mounting plate, PanelSeT SFN, PanelSet SF, W800MM, set of 2
Pricing
Request a quote
We reply within 24 hours
Overview
Schneider Electric NSYSMPSE8 Side entry rails for the mounting plate, PanelSeT SFN, PanelSet SF, W800MM, set of 2 is listed under Enclosures / Enclosure Accessories. Sales unit: pcs; Package quantity: 10 pcs; Product or component type: Rail; Range compatibility: PanelSeT SF SF; Application: Multi-purpose; Mounting location: Bottom of enclosure, in width.
Technical Specifications
- Manufacturer part number (MPN)
- NSYSMPSE8
- EAN / GTIN
- 3606485132228
- Sales unit
- pcs
- Package quantity
- 10 pcs
- category
- Mounting accessory
- Product or component type
- Rail
- Range compatibility
- PanelSeT SF SF
- Application
- Multi-purpose
- Nominal dimensions of the housing
- - D: 800 mm
- Mounting location
- Bottom of enclosure, in width
- Product destination
- Mounting plates in coupled enclosures
- Device composition
- 2 rail; fixing elements
- Quantity per set
- Set of 1
- Material
- Steel
- Surface finish
- Zinc coated
- Fixing mode
- By fixing element
- Adjustment
- Adjustable in depth every 25 mm
- Height
- 48 mm
- Width
- 788 mm
- Depth
- 74 mm
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 6.000 cm
- Package 1 Width
- 9.000 cm
- Package 1 Length
- 80.000 cm
- Package 1 Weight
- 4.338 kg
- Unit Type of Package 2
- PAL
- Number of Units in Package 2
- 10
- Package 2 Height
- 29.000 cm
- Package 2 Width
- 37.500 cm
- Package 2 Length
- 120.000 cm
- Package 2 Weight
- 43.380 kg
- Country of origin
- ES
- Warranty (in months)
- 18
- Model
- Mounting rail
- Suitable for enclosure building width
- 800 mm
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 3606485132228
- SAP 1000317634
- Code 8776307
