Schneider Electric PanelSeT Cable Entry Plate IP65 M63 8-Entry

Schneider Electric NSYTSAM638SE is a circular quick-entrance cable plate for M63 openings with eight cable entries and no connectors. Entries accommodate four cables at 5-9.2 mm, two at 3-6.5 mm and two at 9.6-15.9 mm. Polyamide plate rated IP65, supplied in sets of ten and fitted by clip or screw to PanelSeT S3D, CRN, S3CM, SBM, PLA, PHD, PLM, PLS and S3HD enclosures.

Manufacturer part number (MPN)

NSYTSAM638SE

EAN / GTIN

3606480168161

HS code

8544.42

Sales unit

pcs

Package quantity

10 pcs

Range

PanelSeT

Product or component type

Quick entrance plate

Accessory / separate part category

Cable management accessory

Device application

Multi-purpose

Range compatibility

PanelSeT S3D compact enclosure; PanelSeT CRN compact enclosure; PanelSeT S3CM control enclosure; PanelSeT SBM SBM industrial box; PanelSeT PLA PLA suitable enclosure; PanelSeT PHD suitable enclosure; PanelSeT PLM PLM compact enclosure; PanelSeT PLS PLS insulating modular box; PanelSeT S3HD compact enclosure

Device composition

1 circular plate

Quantity per set

Set of 10

Mounting support

Body of enclosure; Cable gland plate

Material

Polyamide

Fixing mode

Clipped; By screws

Total cable entry number

8

Cable entry number

4 x 5…9.2 mm; 2 x 3…6.5 mm; 2 x 9.6…15.9 mm

Height

Real: 34 mm

Cable outer diameter

63.5 mm; 71 mm

Product weight

0.68 kg

IP degree of protection

IP65

Number of Units in Package 1

1

Number of Units in Package 2

10

Number of Units in Package 3

50

Country of origin

FR

Warranty (in months)

18

HS Code

8544.42

• EAN 3606480168161
• SAP 1000488870
• Code 8268913
