Schneider Electric PanelSeT SF/SM 19" fixed rack - 1600 mm NSYRCK33
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYRCK33 19" Fast frame 33U, height 1600mm, steel.
Technical Specifications
- Manufacturer part number (MPN)
- NSYRCK33
- EAN / GTIN
- 3606480066856
- Sales unit
- pcs
- Rack units
- 33U
- Range
- PanelSeT
- Accessory / separate part category
- Mounting accessory
- Product or component type
- 19" rack
- Application
- Electronic application
- For enclosure nominal dimensions
- - H: 1600 mm
- Rack type
- Fixed
- Mounting location
- On structure of enclosure
- Mounting support
- 19" fixed support bracket
- Range compatibility
- PanelSeT PanelSeT SF; PanelSeT PanelSeT SM
- Device composition
- fixing elements; 2 upright
- Quantity per set
- Set of 1
- Number of units 19"
- 33
- Rack coverage
- Complete
- Material
- Steel
- Enclosure/cubicle description
- Floor-standing enclosure
- Surface finish
- Zinc coated
- fixing mode
- By fixing element
- Adjustment
- Adjustable in depth every 25 mm
- Permanent permissible load
- 400 kg
- Height
- 1600 mm
- Width
- Nominal: 800 mm; Nominal: 600 mm
- Depth
- 60 mm
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 50
- Country of origin
- FR
- Warranty (in months)
- 18
- Suitable for enclosure building width
- 600 mm
- Suitable for enclosure building height
- 1600 mm
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 3606480066856
- SAP 1000089497
- Code 8914594
Product Documentation
