MCB NG125LMA 2P 80A (18876)
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 18876 MCB NG125LMA 2P 80A.
Technical Specifications
- Manufacturer part number (MPN)
- 18876
- EAN / GTIN
- 3303430188766
- Sales unit
- pcs
- Package quantity
- 6 pcs
- Rated current
- 80 A
- Number of poles
- 2P
- Power loss
- 2.7 W
- Built-in depth
- 47 mm
- Release characteristic
- MA
- Number of protected poles
- 2
- Rated voltage
- 230 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- Yes
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 3
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 10–50 mm²
- Connectable conductor cross section solid-core
- 16–70 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430188766
- SAP 1200503043
- Code 82636614
Product Documentation
More from Schneider Electric
Schneider Electric
Illuminated push-button head red LED with boot (ZB4BW543)
Schneider Electric
NG125L/D 10-2 Modular Power Switch
18839
Schneider Electric
EMC Additional Filter IP20 50A
VW3A4704
Schneider Electric
Schneider Electric Climasys Ultra thin resistance heater low starting current 90W 240V 280X450MM NSYCRS100W240V
Schneider Electric
WALL-Mount Cabinet WITH WINDOW. 7X5X2,5
NSYS3D7525T
Schneider Electric
Schneider Electric Control unit MicroLogic 5.0P, ComPacT NS630B to NS1600 fixed and manually operated, selective protections C5PFM
Schneider Electric
Schneider Electric LVS08801 PrismaSeT G Lifting Lug Set of 2
Schneider Electric
Schneider Electric soft STARTER-ATS22-CONTROL 220V-POWER 230V(132kW)/400...440V(250kW) ATS22C48Q
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 18876?
- 18876 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is 18876.
- What is the HS code for 18876?
- The customs tariff (HS) code for 18876 is 8536.20.
- Who manufactures 18876?
- 18876 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for 18876?
- Yes — the 18876 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 18876?
- The minimum order quantity is 1.
- Is 18876 available?
- Yes — 18876 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
