NG125L/D 63-3 Modular Power Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 18855 NG125L/D 63-3 Modular power switch
Technical Specifications
- Manufacturer part number (MPN)
- 18855
- EAN / GTIN
- 3303430188551
- Sales unit
- pcs
- Package quantity
- 18 pcs
- Power loss
- 4 W
- Built-in depth
- 47 mm
- Release characteristic
- D
- Number of poles (total)
- 3
- Number of protected poles
- 3
- Rated current
- 63 A
- Rated voltage
- 415 V
- Rated insulation voltage Ui
- 690 V
- Rated impulse withstand voltage Uimp
- 8 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- No
- Overvoltage category
- 4
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 4.5
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -30–70 °C
- Connectable conductor cross section multi-wired
- 1–35 mm²
- Connectable conductor cross section solid-core
- 1.5–50 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430188551
- SAP 1000085608
- Code 8819092
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric Soft starter, Altistart 480, 250A, 208 to 690V AC, control supply 110 to 230V AC ATS480C25Y
Schneider Electric
Retrofit bracket f/ G115-225
LA9GRFB1
Schneider Electric
Schneider Electric Solid state panel mount relay, 75 A, zero voltage switching, thermal pad, input 90…280 V AC, output 48…660 V AC SSP1A475M7T
Schneider Electric
Schneider Electric Residual current breaker with overcurrent protection (RCBO), ACTI9 iDPN N Vigi, 1P+N, 13A, B curve, 6000A, A type, 30MA A9D56613
Schneider Electric
Schneider Electric Contactor, TeSys Deca, 3P(3NO), AC-3/3E, <=440V, 32A, 220V AC 50/60Hz coil, screw clamp terminals LC1D32M7
Schneider Electric
Schneider Electric Circuit breaker, ComPacT NSX250HB1, 75KA/690VAC, 4 poles, MicroLogic 5.2E trip unit 250A C25V45E250
Schneider Electric
ESI frame for open kabling
FFS06728093
Schneider Electric
Schneider Electric PanelSet S3HF H600XW600XD250 EMC-immunity IP55 RAL7035 NSYS3HF6625P
Technical guides
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 18855?
- 18855 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is 18855.
- What is the HS code for 18855?
- The customs tariff (HS) code for 18855 is 8536.20.
- Who manufactures 18855?
- 18855 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for 18855?
- Yes — the 18855 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 18855?
- The minimum order quantity is 1.
- Is 18855 available?
- Yes — 18855 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
