Schneider Electric SCU - DIN - remote control dimmer - 1..10 V CCTDD20011

Schneider Electric CCTDD20011 Modular dimmer 1-10V SCU10.

Manufacturer part number (MPN)

CCTDD20011

EAN / GTIN

3606480160684

HS code

8536.90

Sales unit

pcs

Package quantity

24 pcs

range of product

Acti9

Product name

Acti9 SCU

Product or component type

Remote control dimmer

Device short name

SCU

Device application

Building

Load type

50 x fluocompact lamp, electronic ballast: <= 1500 W; 12 x dual mounted fluorescent tube, electronic ballast: 58 W; 20 x dual mounted fluorescent tube, electronic ballast: 36 W; 25 x fluorescent tube, electronic ballast: 58 W; 40 x dual mounted fluorescent tube, electronic ballast: 18 W; 40 x fluorescent tube, electronic ballast: 36 W; 50 x fluorescent tube, electronic ballast: 18 W

Control type

Local control: push-button; Remote control: push-button

Power consumption in VA

0.8 VA

Thermal losses

3 W

[Ue] rated operational voltage

230 V AC +/- 10 % at 50 Hz

Output current

0.2...100 mA

Protection type

Electronic overvoltage protection; Electronic over temperature protection; Single shot thermal fuse; Electronic overload protection

Mounting support

DIN rail

9 mm pitches

8

Connected auxiliaries

Maximum 25 auxiliary push-buttons without light indication, distance : < 50 m; Maximum 5 auxiliary push-buttons with light indication, distance : < 50 m

Connections - terminals

Screw terminals, 2 cable(s) 4 mm² top

Height

85 mm

Width

72 mm

Depth

62 mm

Product weight

130 g

IP degree of protection

IP20

Standards

EN 60669-2-1

Directives

89/336/EEC - electromagnetic compatibility; 73/23/EEC - low voltage directive

Ambient air temperature for operation

0…70 °C

Ambient air temperature for storage

0…60 °C

Number of Units in Package 1

1

Number of Units in Package 2

24

Warranty (in months)

18

HS Code

8536.90

• EAN 3606480160684
• SAP 1000516373
• Code 8632182
