Schneider Electric STD - DIN - remote control dimmer - 1000 W CCTDD20003
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric CCTDD20003 Modular dimmer1kW STD1000RL.
Technical Specifications
- Manufacturer part number (MPN)
- CCTDD20003
- EAN / GTIN
- 3606480160660
- Sales unit
- pcs
- Package quantity
- 24 pcs
- range of product
- Acti9
- Product name
- Acti9 STD
- Product or component type
- Remote control dimmer
- Device short name
- STD
- Device application
- Building
- Load type
- 230 V AC halogen lamp: 60...1000 W; 230 V AC incandescent lamp: 60...1000 W; low voltage halogen lamp with conventional transformer: 60...1000 W; motor: 60...600 W
- Control type
- Local control: push-button; Remote control: push-button
- Power consumption in VA
- 0.8 VA
- Thermal losses
- 3 W
- Input type
- Push-button
- [Ue] rated operational voltage
- 230 V AC +/- 10 % at 50 Hz
- Protection type
- Electronic over temperature protection; Electronic overvoltage protection; Single shot thermal fuse; Electronic overload protection
- Mounting support
- DIN rail
- 9 mm pitches
- 8
- Connected auxiliaries
- Maximum 25 auxiliary push-buttons without light indication, distance : < 50 m; Maximum 5 auxiliary push-buttons with light indication, distance : < 50 m
- Connections - terminals
- Screw terminals, 2 cable(s) 4 mm² top
- Height
- 85 mm
- Width
- 72 mm
- Depth
- 62 mm
- Product weight
- 120 g
- IP degree of protection
- IP20
- Standards
- EN 60669-2-1
- Directives
- 73/23/EEC - low voltage directive; 89/336/EEC - electromagnetic compatibility
- Ambient air temperature for operation
- 0…70 °C
- Ambient air temperature for storage
- 0…60 °C
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 24
- Warranty (in months)
- 18
- Mounting method
- DIN rail
- Function
- Dimmer
- Central function OUT
- Yes
- Group switch
- No
- Panic function
- No
- Presence simulation
- No
- Stair light and forewarn
- No
- Number of universal dim channels
- 1
- Number of dimmer functions
- 1
- Weekly program
- No
- Astro program
- No
- Rain sensor
- Yes
- Number of channels
- 1
- Control voltage 1
- 12–30 V
- Rated current
- 4 A
- Dim capacity per channel
- 1000 W
- Rated voltage
- 230 V
- Rated frequency
- 50–60 Hz
- Degree of protection (IP)
- IP20
- Width in number of modular spacings
- 4
- Country of origin
- Latvia
Standards & Compliance
- HS Code
- 8537.10
Cross References
- EAN 3606480160660
- SAP 1000516371
- Code 8632178
Product Documentation
