Main pole 20A (VZN20)

Schneider Electric VZN20 Main pole 1P 20A.

Manufacturer part number (MPN)

VZN20

EAN / GTIN

3389110760033

Sales unit

pcs

Package quantity

70 pcs

Rated current

20 A

Range

TeSys

Device short name

VZN

Product or component type

Additional pole

Performance level

Standard

Poles description

1P

Contacts type and composition

1 NO

Product compatibility

VN20

Network type

DC; AC

Network frequency

50/60 Hz

Mounting location

Left; Right

Range compatibility

TeSys TeSys VARIO VCFN switch disconnector

[Ue] rated operational voltage

690 V AC 50/60 Hz

[Uimp] rated impulse withstand voltage

6 kV

[Ith] conventional free air thermal current

20 A

[Ithe] conventional enclosed thermal current

16 A

Mechanical durability

50000 cycles

Electrical durability

30000 cycles DC-1...5; 50000 cycles AC-21

Suitability for isolation

Yes

Connections - terminals

Power circuit: screw clamp terminals4 mm² - flexible - with cable end; Power circuit: screw clamp terminals4 mm² - solid

Tightening torque

Power circuit: 0.7 N.m - on screw clamp terminals

Height

45.5 mm

Width

12 mm

Depth

39 mm

Product weight

0.02 kg

Standards

IEC 60947-3

Product certifications

GL; UL; CSA

Protective treatment

TC

IP degree of protection

IP20 conforming to IEC 60529

Mechanical robustness

Shocks 11 ms (15 gn) conforming to IEC 60068-2-27; Vibrations 10...150 Hz (1 gn) conforming to IEC 60068-2-6

Ambient air temperature for operation

-20…50 °C

Fire resistance

960 °C conforming to IEC 60695-2-1

Number of Units in Package 1

1

Number of Units in Package 2

70

Country of origin

CZ

Warranty (in months)

18

HS Code

8538.90
