Schneider Electric TeSys VARIO - auxiliary contact block - 1 NC early-break+1 NO late-make VZ7

Schneider Electric VZ7 Auxiliary Contact Block 1NO+1NC.

Manufacturer part number (MPN)

VZ7

EAN / GTIN

3389110551969

Sales unit

pcs

Package quantity

69 pcs

Range

TeSys

Device short name

VZ

Product or component type

Auxiliary contact block

Performance level

High performance

Contacts type and composition

1 NO + 1 NC

Contact operation

Late-make 1 NO; Early-break 1 NC

Product compatibility

V2; V5; V02; V6; V1; V4; V01; V0; V3

Network type

AC; DC

Network frequency

50/60 Hz

Mounting location

Left; Right

[Ue] rated operational voltage

690 V AC 50/60 Hz

[Uimp] rated impulse withstand voltage

8 kV

[Ith] conventional free air thermal current

12 A

[Ithe] conventional enclosed thermal current

10 A

Mechanical durability

100000 cycles

Electrical durability

30000 cycles DC-11; 100000 cycles AC-15

Connections - terminals

Screw clamp terminals 2 cable(s) 0.75…1.5 mm² - flexible - with cable end; Screw clamp terminals 2 cable(s) 1…2.5 mm² - solid

Tightening torque

0.7 N.m - on screw clamp terminals

Height

65 mm

Width

20 mm

Depth

48.5 mm

Product weight

0.05 kg

Standards

IEC 60947-5

Product certifications

GL; CSA; UL; UKCA

Protective treatment

TC

IP degree of protection

IP20 conforming to IEC 60529

Ambient air temperature for operation

-20…50 °C

Fire resistance

960 °C conforming to IEC 60695-2-1

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

5.500 cm

Package 1 Width

3.700 cm

Package 1 Length

9.000 cm

Package 1 Weight

52.000 g

Unit Type of Package 2

S02

Number of Units in Package 2

69

Package 2 Height

15.000 cm

Package 2 Width

30.000 cm

Package 2 Length

40.000 cm

Package 2 Weight

3.931 kg

Country of origin

CZ

Warranty (in months)

18

HS Code

8538.90
