Schneider Electric Harmony K30F013UP — cam switch, changeover, 2-Position 3-Pole

Schneider Electric Harmony K30F013UP is a complete cam switch configured as a 3-pole changeover with no OFF position, operating over two positions with 30° right-hand indexing. It offers a rated insulation voltage [Ui] of 690 V at pollution degree 3 and a 6 kV impulse withstand per IEC 60947-1, short-circuit protection by a 50 A gG cartridge fuse, and captive screw-clamp terminals accepting 2 × 6 mm² solid conductors. Protection IP40 per IEC 60529. El-nummer 1402604, EAN 3389110084153.

Range

Harmony K

Device

complete cam switch, changeover, without OFF position

Poles

3-pole

Positions

2 positions, 30° indexing (right-hand)

Rated insulation voltage [Ui]

690 V (pollution degree 3) per IEC 60947-1

Impulse withstand voltage

6 kV per IEC 60947-1 / EN 60947-1

Short-circuit protection

50 A cartridge fuse, type gG

Terminals

captive screw-clamp, solid, clamping capacity 2 × 6 mm²

Degree of protection

IP40 per IEC 60529

El-nummer

1402604

EAN

3389110084153

Model

Reverser

Rated permanent current Iu

32 A

Number of poles

3

With zero (off) position

No

With retraction in 0-position

No

Degree of protection (IP), front side

IP40

Type of electrical connection of main circuit

Screw connection

Type of control element

Long rotary handle

Suitable for floor mounting

No

Suitable for front mounting

Yes

Suitable for distribution board installation

No

Suitable for intermediate mounting

Yes

Complete device in housing

Yes

Country of origin

Austria

HS Code

8536.50

• EAN 3389110084153
• SAP 1200502646
• Code 82626524
