CMC III Access Control

Rittal 7030202 CMC III Access Control.

Manufacturer part number (MPN)

7030202

EAN / GTIN

4028177925847

Sales unit

pcs

Model designation

DK 7030.202

Product type

CMC III access control

Function principle

For connecting one handle and one reader unit to monitor a door; Integral IR access sensor

Design

Record of every access and each time the door is opened, with user information and time stamp; Supports one central reader unit per CMC III system; Fixed allocation between handles and reader units; Four-eyes principle; Central administration of access rights across all systems and locations with RiZone; Activating the LED display in the handle

Material

Plastic; Front: Smooth; Enclosure: Textured

Surface finish

Front: Smooth; Enclosure: Textured

Colour

Front: RAL 9005; Enclosure: RAL 7035

Supply includes

CMC III access control; Mounting plate; Assembly parts

Interface bus system

2 x RJ45 CAN bus

Interfaces

RJ12; Flat-pin connector

No. of participating PU (max.)

16

Dimensions

Width: 110 mm; Height: 30 mm; Depth: 40 mm

Operating temperature range

0 °C...55 °C

Ambient humidity (non- condensing)

5...95 %

Net weight

0.175 kg

Gross weight

0.183 kg

Customs tariff number

85311095

ETIM 9

EC002627

ECLASS 8.0

27189253

Approvals

UL + C-UL (listed)

Country of origin

Germany

HS Code

8531.10

• EAN 4028177925847
• SAP 1200493170
• Code 82691176
