Phoenix Contact PLC-RPT-24UC/21 Relay Module, 24 V AC/DC, 1 CO

The PLC-RPT-24UC/21 (order code 2900300) is a plug-in relay module from the Phoenix Contact PLC interface family, rated for 19.4–33.6 V AC/DC coil supply. It provides one changeover contact for signal switching in PLC and control-cabinet applications, with LED status indication and mono-stable polarised drive. Housing width 6.2 mm on DIN rail.

Manufacturer part number (MPN)

PLC-RPT- 24UC/21

EAN / GTIN

4046356509008

Sales unit

pcs

Package quantity

10 pcs

Product type

Relay Module

Manufacturer order number

2900300

With detachable clamps

No

Nominal current

0.011 A

Rated control supply voltage AC 50 Hz

19.4–33.6 V

Rated control supply voltage AC 60 Hz

19.4–33.6 V

Rated control supply voltage DC

19.4–33.6 V

Voltage type for actuating

AC/DC

Drive, polarization

Polarized

Drive, switching attitude

Mono stable

Number of contacts as change-over contact

1

With forced-guided contacts

No

Type of switch contact

Single contact

Complete with socket

Yes

With LED indication

Yes

Material of contact surface

Untreated

Degree of protection (IP)

IP20

Width

6.2 mm

Height

80 mm

Depth

94 mm

Country of origin

Germany

HS Code

8536.49

• EAN 4046356509008
• SAP 1000165950
• Code 8170993
