Phoenix Contact ST 6-TWIN Spring-Clamp Terminal Block 4-Connection 0.2-6 mm² Grey

Phoenix Contact ST 6-TWIN is a grey spring-clamp feed-through terminal block for aluminium and copper conductors from 0.2 to 10 mm² solid and 0.2 to 6 mm² stranded, rated 41 A at 1000 V. It mounts on 35 mm DIN top-hat rail with three clamp positions across a single level, and is certified for Ex e explosion-protected applications. The housing measures 8.2 mm wide, 90.5 mm high and 43.5 mm deep with an operating range of -60 to 110 °C; supplied in packs of 50.

Manufacturer part number (MPN)

ST 6-TWIN

EAN / GTIN

4017918884659

Sales unit

pcs

Package quantity

50 pcs

Suitable for conductor material

Aluminium/copper

Connectable conductor cross section solid-core

0.2–10 mm²

Connectable conductor cross section multi-wired

0.2–6 mm²

Rated current In

41 A

Rated voltage

1000 V

Type of electrical connection 1

Spring clamp connection

Type of electrical connection 2

Spring clamp connection

Connection position

Atop

Number of levels

1

Number of clamp positions per level

3

Mounting method

DIN rail (top hat rail) 35 mm

Operating temperature

-60–110 °C

Width

8.2 mm

Width/grid dimension

8.2 mm

Height

90.5 mm

Depth

43.5 mm

Length

90.5 mm

Explosion-tested version 'Ex e'

Yes

Closing plate required

Yes

Colour

Grey

Internally connected stages

Yes

Country of origin

China

HS Code

8536.90

• EAN 4017918884659
• SAP 1000283692
• Code 8988533
