Phoenix Contact ST 4 Spring-Cage Terminal Block, 0.08–4.0 mm², Ex e

The ST 4 is a single-level spring-clamp terminal block from Phoenix Contact, mounted on 35 mm DIN rail with a 6.2 mm grid dimension. Rated at 32 A and 800 V for solid conductors up to 6 mm², it accepts flexible conductors from 0.08 to 4 mm² without pre-treatment. The block is Ex-e certified and rated from -60 to +110 °C.

Manufacturer part number (MPN)

ST 4

EAN / GTIN

4017918186838

Sales unit

pcs

Package quantity

50 pcs

Conductor cross-section

0.08-4.0 mm²

Suitable for conductor material

Aluminium/copper

Connectable conductor cross section solid-core

0.08–6 mm²

Connectable conductor cross section multi-wired

0.08–4 mm²

Rated current In

32 A

Rated voltage

800 V

Type of electrical connection 1

Spring clamp connection

Type of electrical connection 2

Spring clamp connection

Number of levels

1

Number of clamp positions per level

2

Mounting method

DIN rail (top hat rail) 35 mm

Operating temperature

-60–110 °C

Width

6.2 mm

Width/grid dimension

6.2 mm

Height

56 mm

Depth

36.5 mm

Length

56 mm

Explosion-tested version 'Ex e'

Yes

Closing plate required

Yes

Colour

Grey

Internally connected stages

Yes

Country of origin

Germany

HS Code

8536.90

• EAN 4017918186838
• SAP 1000052137
• Code 8817247
