Phoenix Contact UTME 6 screw-clamp knife-disconnect terminal

Phoenix Contact UTME 6 is a single-level screw-clamp knife-disconnect (test) terminal block for DIN rail mounting on 35 mm top-hat rail. It accepts solid conductors 0.2–10 mm² and stranded conductors 0.2–2.5 mm², rated 30 A at 500 V. Grey housing, width 8.2 mm, height 100.8 mm, depth 49.6 mm; closing plate required.

Manufacturer part number (MPN)

UTME 6

EAN / GTIN

4046356291101

Sales unit

pcs

Package quantity

50 pcs

Connectable conductor cross section solid-core

0.2–10 mm²

Connectable conductor cross section multi-wired

0.2–2.5 mm²

Rated current In

30 A

Rated voltage

500 V

Type of electrical connection 1

Screw connection

Type of electrical connection 2

Screw connection

Number of levels

1

Number of clamp positions per level

2

Internally connected stages

Yes

Mounting method

DIN rail (top hat rail) 35 mm

Operating temperature

-60–105 °C

Width

8.2 mm

Width/grid dimension

8.2 mm

Height

100.8 mm

Depth

49.6 mm

Closing plate required

Yes

Colour

Grey

With integrated test socket

No

Length

100.8 mm

Country of origin

Poland

HS Code

8536.90

• EAN 4046356291101
• SAP 1000657044
• Code 8477428
