Omron E3ZLS81 Background Suppression Photoelectric Sensor, 40-200 mm, PNP, 2 m Cable

Omron E3ZLS81 is a diffuse-reflective photoelectric sensor with background suppression, sensing objects from 40 to 200 mm regardless of surface colour. Output is PNP normally-open with a maximum current of 100 mA on a three-conductor DC connection, delivered on a fixed 2 m cable exiting a cuboid 10.8 x 20 x 31 mm housing. A separate bracket is required for mounting.

Manufacturer part number (MPN)

E3ZLS81

EAN / GTIN

4536854844836

HS code

8544.42

Sales unit

pcs

Output type

PNP

Adjustment range

20–200 mm

Triangulation

Background fade-out

Pre failure notice

No

With time function

No

Rated switching distance

200 mm

Max. switching distance

200 mm

Max. output current

100 mA

With reflector

No

Analogue output 0 V ... 10 V

No

Analogue output 0 mA ... 20 mA

No

Analogue output 4 mA ... 20 mA

No

Analogue output -10 V ... +10 V

No

With other analogue output

No

Setting procedure

Manual adjustment

With communication interface analogue

No

With communication interface AS-Interface

No

With communication interface CANOpen

No

With communication interface DeviceNet

No

With communication interface Ethernet

No

With communication interface INTERBUS

No

With communication interface PROFIBUS

No

With communication interface RS-232

No

With communication interface RS-422

No

With communication interface RS-485

No

With communication interface SSD

No

With communication interface SSI

No

Number of semiconductor outputs with signalling function

1

Type of electric connection

Cable

Type of switching output

PNP

Type of switch function

Normally open contact (NO)

Operation agent-safety class

Safety class 0

Explosion safety category for gas

None

Explosion safety category for dust

None

Construction type housing

Cuboid

Width sensor

10.8 mm

Height of sensor

31 mm

Length of sensor

20 mm

Sensing mode

Light-/dark switching

Material of optical surface

Plastic

Housing material

Plastic

Max. output current at protected output

100 mA

Min. reflector distance

0 mm

Ambient temperature

-25–55 °C

Response time

1 ms

Switching frequency

1000 Hz

Type of safety according to IEC 61496-1

1

Rated control supply voltage DC

10–30 V

Voltage type

DC

With monitoring function downstream switching devices

No

Laser protection class

None

Wavelength of the sensor

680 nm

Type of light

Polarity free red light

AWG-number

24

Material of cable sheath

Polyvinyl chloride (PVC)

With restart blockage

No

Suitable for safety functions

No

Degree of protection (IP)

IP67

Country of origin

China

HS Code

8544.42

• EAN 4536854844836
• SAP 1000156884
• Code 8112113
