Melbye A2565G Insulated Flanged Fork (Spade) Terminal 1.5–2.5 mm² M6 (Blue)
Pricing
Request a quote
We reply within 24 hours
Product Description
Melbye A2565G — insulated flanged fork (spade) terminal for a 1.5–2.5 mm² copper conductor, for an M6 screw stud (fork slot Ø 6.5 mm). Tinned 99.95% copper barrel with a brazed neck in a halogen-free polycarbonate easy-entry sleeve, colour-coded blue for the conductor range. The open fork slot fits over a screw stud without removing the nut; crimped to stranded or fine-stranded copper conductors (IEC 60228) with matching Elpress/Abiko dies for terminal-block, contactor and distribution-equipment terminations.
Technical Specifications
- Type
- Insulated flanged fork (spade) terminal
- Conductor cross-section
- 1.5–2.5 mm²
- Stud size
- M6 (fork slot Ø 6.5 mm)
- Terminal form
- Fork (spade), open slot
- Insulation
- Halogen-free polycarbonate (PC) easy-entry sleeve
- Insulation colour code
- Blue
- Material
- Copper 99.95%, tin-plated, brazed neck
- Conductor
- Stranded / fine-stranded copper (IEC 60228)
- Series
- A (pre-insulated)
- Manufacturer part number (MPN)
- A2565G
- EAN / GTIN
- 7070701016719
- Sales unit
- pcs
- HS code
- 8536.90
- Surface protection
- Tinned
- Total length
- 22.5 mm
- Max. current (Imax)
- 16 A
- Flange shape
- Fork shape
- For pull protected connections
- No
- Reel/roll packaging
- No
- Colour insulation
- Blue
- Bolt dimension (metric)
- 6
- AWG-range
- 14–16
- Nominal cross section
- 1.5–2.5 mm²
- Suitable for fine strand conductors
- Yes
- Suitable for flat conductors
- No
- Suitable for high temperatures (to 650 °C)
- No
- Suitable for insulated varnish
- No
- Suitable for solid conductors
- Yes
- Suitable for stranded conductors
- Yes
- Suitable for round conductors
- Yes
- Sleeve form
- Short
- According to DIN
- No
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7070701016719
- SAP 1000038347
- Code 8780401
