Mascot 2045 24 V 10 A Three-Step Lead-Acid Battery Charger
Pricing
Request a quote
We reply within 24 hours
Product Description
The Mascot 2045 is a 24 V 10 A three-step switch-mode charger for lead-acid batteries with a recommended capacity range of 50-500 Ah and a float-charging final stage. Fast constant-current bulk charging is followed by absorption and float, allowing the load to remain connected in parallel and recovering deeply discharged cells. Housed in an aluminium enclosure 186 x 63.5 x 215 mm rated IP20, with crocodile clips, short-circuit and thermal protection; typical use is back-up and starter-battery service at -25 to +40 degrees C.
Technical Specifications
- Manufacturer part number (MPN)
- 2045 3-STEGS BLY LA
- EAN / GTIN
- 7057070001614
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 8 pcs
- Voltage
- 24 V
- Rated current
- 10 A
- Battery technology
- Lead acid
- Suitable for starter batteries
- Yes
- Suitable for industrial batteries
- Yes
- Nominal input voltage 1
- 230 V
- Frequency
- 50/60 Hz
- Recommended battery capacity
- 50–500 Ah
- Max. loading current
- 10 A
- Float charger
- Yes
- Number of outgoing connections
- 1
- Power factor
- 83
- Ambient temperature
- -25–40 °C
- Overload-/temperature protection
- Yes
- Connector
- Crocodile clip
- Short-circuit protected
- Yes
- Degree of protection (IP)
- IP20
- Housing material
- Aluminium
- Height
- 63.5 mm
- Width
- 186 mm
- Depth
- 215 mm
- Country of origin
- Estonia
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7057070001614
- SAP 1000079138
- Code 8835967
Product Documentation
