Han CGM-M M25X1,5 D.9-16MM/13-18MM
Pricing
Request a quote
We reply within 24 hours
Product Description
Harting 19000005091 Manufacturer description: Cable gland; M25; Clamping range: 9. 18 mm; Material (cable glands): Brass; Material (clamping ring): Polyamide (PA); IP68, IP69 / IPX9K acc. to ISO 20653; Wrench size: 30. Nipple, M25, Klem dia: 9. 18mm, Brass, Nickel plated.
Technical Specifications
- Manufacturer part number (MPN)
- 19000005091
- EAN / GTIN
- 5713140039117
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Category
- Accessories
- Series of hoods/housings
- Han® CGM-M
- Type of accessory
- Cable gland
- Limiting temperature
- -40 ... +100 °C
- Tightening torque
- ≤12 Nm (depending on the cable and the seal insert used)
- Wrench size
- 30
- Degree of protection acc. to IEC 60529
- IP68 | IP69 / IPX9K acc. to ISO 20653
- Size
- M25
- Clamping range
- 9 ... 18 mm
- Width across corners
- 33.5 mm
- ECHA SCIP number
- 6d86e660-27db-4390-811a-374604e3d289
- China RoHS
- 50
- RoHS
- compliant with exemption
- REACH SVHC substances
- Yes | 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol | Lead
- REACH Annex XVII substances
- Not contained
- REACH ANNEX XIV substances
- Not contained
- ELV status
- compliant with exemption
- California Proposition 65 substances
- Yes | Lead | Nickel
- RoHS exemptions
- 6(c): Copper alloy containing up to 4 % lead by weight
- Material (seal)
- NBR
- Material (cable glands)
- Brass
- Material (clamping ring)
- Polyamide (PA)
- Surface (accessories)
- Nickel plated
- UL / CSA
- UL 514B QCRV.E479780 | CSA-C22.2 No. 18.3 QCRV7.E479780
- Approvals
- DNV GL
- European customs tariff number
- 74122000
- Packaging size
- 10
- Net weight
- 50 g
- Country of origin
- Germany
- eCl@ss
- 27140801 Screwed cable gland (electrical)
- ETIM
- EC000441
- UNSPSC 24.0
- 39121431
- Width
- 21 mm
- Height
- 21 mm
- Depth
- 36.7 mm
- Rated voltage
- 600 V
- With wire protection
- No
- With housing
- No
- Suitable for distribution board
- No
- Number of poles
- 4
- Contact type
- Bus
- Ambient temperature
- -40–125 °C
- Operating temperature
- -40–125 °C
- Rated surge voltage
- 4 kV
- Type of electric connection
- Spring clamp connection
- Material of contact surface
- Silver
- Overvoltage category
- III
- Pollution degree
- 3
- Diameter plug-in contact
- 1.6 mm
- Contact insert without contacts
- No
- Connectable conductor cross section solid-core
- 0.5–2.5 mm²
- Connectable conductor cross section multi-wired
- 0.5–2.5 mm²
- With protective conductor
- Yes
- Material contact
- Other copper alloys
- Material connector insert
- Thermoplastic
- Rated current In
- 10 A
- Material of contact insert
- Thermoplastic
- Min. number of insertion cycles
- 500
- Number of power contacts
- 4
