Circuit breaker TM 3X101-160A 40K (HNA160H)
Pricing
Request a quote
We reply within 24 hours
Product Description
Hager Systemer HNA160H Circuit breaker, thermal and magnetic switch-off, adjustable 3x101 for 160A (Ir 0,63-0,8-1xIn) Ik 40kA.
Technical Specifications
- Manufacturer part number (MPN)
- HNA160H
- EAN / GTIN
- 3250613130862
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 9 pcs
- Rated permanent current Iu
- 160 A
- Number of poles
- 3
- Overload release current setting
- 100–160 A
- Rated voltage
- 220–440 V
- Degree of protection (IP)
- IP40
- Position of connection for main current circuit
- Front side
- Motor drive integrated
- No
- Type of electrical connection of main circuit
- Screw connection
- Type of control element
- Wing knob
- With switched-off indicator
- No
- Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
- 40 kA
- Adjustment range undelayed short-circuit release
- 1600 A
- Suitable for DIN rail (top hat rail) mounting
- Yes
- Integrated earth fault protection
- No
- Motor drive optional
- No
- Device construction
- Built-in device fixed built-in technique
- DIN rail (top hat rail) mounting optional
- Yes
- Complete device with protection unit
- Yes
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3250613130862
- SAP 1000573394
- Code 8686498
Product Documentation
More from Hager Systemer
Hager Systemer
Slisset CABLE TRUNKING,32X18MM 1 Pcs=2 M
BA63001507030B
Hager Systemer
Slotted WIRING DUCT,40X40MM BLUE 2M
BA740040BL
Hager Systemer
Miniature circuit breaker 4X100A, c-kar 15KA, 6-Mod
HMC490
Hager Systemer
univers N kit, montplate data, H600XB250
UD41M1
Hager Systemer
Flat angle FOR LF/FB60110 White
LF6011059016
Hager Systemer
Isopor, VR10 round 275mm H=200
SEVR10200
Hager Systemer
Flat angle / L angle for LF 60X90 WHITE
LFF6009059016
Hager Systemer
Slisset Cable Trunking 85X67MM L=2
BA68006007030B
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy HNA160H?
- HNA160H can be ordered from cballast.com as a Hager Systemer catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Hager Systemer product?
- The manufacturer part number is HNA160H.
- What is the HS code for HNA160H?
- The customs tariff (HS) code for HNA160H is 8536.90.
- Who manufactures HNA160H?
- HNA160H is a Hager Systemer product in the Electrical Components range.
- Is a datasheet available for HNA160H?
- Yes — the HNA160H datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for HNA160H?
- The minimum order quantity is 1.
- Is HNA160H available?
- Yes — HNA160H is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
