Hager ERD218 Modular Contactor 16 A 24 V, 1 NO + 1 NC with Front Switch

Hager ERD218 is a modular DIN-rail contactor rated 16 A with a 24 V AC/DC coil and one normally open plus one normally closed contact. The front-mounted manual slider allows local override, and the unit occupies one module width with 60 mm mounting depth. It is suited to lighting circuits up to 1100 W incandescent or 570 VA fluorescent load per AC-7a/AC-7b utilisation. Country of origin France.

Manufacturer part number (MPN)

ERD218

EAN / GTIN

3250612400508

HS code

8536.90

Sales unit

pcs

Package quantity

108 pcs

Utilization category according to EN IEC 60947-4-1

AC-7a/AC-7b

Rated operating voltage

230–400 V

Rated operation current

16 A

Utility category

7

Rated excitation voltage

24 V

Voltage type (operating voltage)

AC/DC

Number of contacts as normally open contact

1

Number of contacts as normally closed contact

1

Max. incandescent lamp load

1100 W

Max. load fluorescent lamp

570 VA

Slider for hand switch

Yes

Width in number of modular spacings

1

Built-in depth

60 mm

Additional equipment possible

Yes

With day/night function

No

Hum-free

No

Degree of protection (IP)

IP2X

Country of origin

France

HS Code

8536.90
