Hager Systemer
Cronotec UR 1K 16A UKE 12/24V
Part numberEG103VEAN / GTIN3250612279937HS code9107.00
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Hager Systemer EG103V Cronotec Ur 1-Channel 16A Uke 12/24V.
Technical Specifications
- Manufacturer part number (MPN)
- EG103V
- EAN / GTIN
- 3250612279937
- Sales unit
- pcs
- Package quantity
- 48 pcs
- Voltage
- 12/24 V
- Rated current
- 16 A
- Shortest switching time channel 1
- 1 s
- Shortest switching time channel 2
- 1 s
- Mounting method
- DIN rail
- Number of channels
- 1
- Supply voltage
- 12–24 V
- Voltage type (supply voltage)
- AC
- Frequency supply voltage
- 50 Hz
- Autonomy in hours
- 5
- Autonomy in years
- 5
- Accuracy per day
- 1.5 s
- Text guidance in display
- No
- External programming
- Yes
- With memory card
- No
- 60 min program
- No
- 24 h program
- No
- Weekly program
- Yes
- Annual program
- No
- Holiday program
- Yes
- Impulse program
- Yes
- Cycle program
- No
- Astro program
- No
- Random program
- Yes
- Hour meter
- No
- Mains synchronous
- No
- Quartz controlled
- Yes
- Radio-controlled
- No
- GPS (global positioning system)
- No
- Contact type
- Change-over contact
- Automatic switching summer/winter time
- Yes
- Suitable for manual operation
- Yes
- External push button input
- No
- Switching preselection
- No
- Nominal switching current at 250 V AC
- 16 A
- Potential free switch contact
- Yes
- Degree of protection (IP)
- IP20
- Width in number of modular spacings
- 2
- Width
- 35 mm
- Height
- 85 mm
- Depth
- 64 mm
- Country of origin
- France
Standards & Compliance
- HS Code
- 9107.00
Cross References
- EAN 3250612279937
- SAP 1000286532
- Code 881563
Product Documentation
Document preview: Cronotec UR 1K 16A UKE 12/24V (EG103V) — Specification sheet
