Hager PACPOST 80 Double-Sided Service Pillar 650 mm White
Pricing
Request a quote
We reply within 24 hours
Product Description
Hager DAP2806509016 is a PACPOST 80 double-sided service pillar 650 mm high, 65 x 98 mm cross-section, in white aluminium (RAL 9016) with wet-varnished halogen-free finish. The rectangular column carries two usable cover faces for outlet and data modules, with a through-going internal profile and 10,800 mm² usable cable cross-section. Cable entry is available at both top and bottom and the column is suitable for ceiling or floor mounting. Typical application is desktop and workstation power/data delivery in open-plan offices and meeting rooms.
Technical Specifications
- Manufacturer part number (MPN)
- DAP2806509016
- EAN / GTIN
- 4012740015837
- Sales unit
- pcs
- Pillar shape
- Rectangular
- Model
- Double-sided
- Pre-wired
- No
- Adjustable
- Yes
- Column height
- 650 mm
- Column depth
- 98 mm
- Column width
- 65 mm
- Diameter
- 65 mm
- Number of usable covers
- 2
- Cover width
- 98 mm
- Cover depth
- 65 mm
- Place variable
- Yes
- Cable entry
- Top/bottom
- Through-going profile
- Yes
- Material installation column
- Aluminium
- Material installation column halogen free
- Yes
- Surface protection column
- Wet varnished
- Colour column
- White
- RAL-number column
- 9016
- Material cover
- Aluminium
- Material cover halogen free
- Yes
- Cover surface
- Wet varnished
- Colour top cover
- White
- RAL-number cover
- 9016
- Number of partitions
- 1
- Usable cross section
- 10800 mm²
- Suitable for ceiling mounting
- Yes
- Suitable for floor mounting
- Yes
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 7326.90
Cross References
- EAN 4012740015837
- SAP 1200524547
- Code 82686485
Product Documentation
