Graco XM70 System, 480V, Wall Power, Viscon HF Heaters, Junction Box, No Feed System, Remote Manifold
Pricing
Request a quote
We reply within 24 hours
Product Description
Graco XM7H00 XM70 System, 480V, Wall Power, Viscon HF Heaters, Junction Box, No Feed System, Remote Manifold, part number XM7H00. Plural Component Sprayer (XM70). Mix ratio 1:1-10:1. Maximum working pressure 6300 psi (435 bar); maximum fluid flow 3 gpm (11.4 lpm). All values read from the Graco product page (XM7H00 on graco.com).
Technical Specifications
- Brand
- Graco Model: XM70 Part number: XM7H00 Maximum working pressure: 6300 psi (435 bar) Maximum flow rate: 3 gpm (11.4 lpm) Type: Plural Component Sprayer minimum mix ratio: 1:1 Maximum mix ratio: 10:1 Mix accuracy: 5% Tank capacity: No Tank Power source: Wall Air inlet size: 3/4 in. Female NPT Sound pressure level: 84.8 at 70psi (0.48 MPa, 4.8 bar) dB(A) Voltage: 480 V
Standards & Compliance
- Pressure Rating
- 6300 psi (435 bar) max working
- HS Code
- 8424.20
Compatibility & Fitment
XM is Graco's plural-component (two-component) proportioning spray line for protective coatings and materials. The 1:1-10:1 mix ratio range and the wetted-material set determine which coatings this configuration handles. Confirm the electrical supply (phase/voltage), hopper/feed configuration and gun/tip suit the coating before ordering.
