Graco LP315 RAC X LP SwitchTip reversible airless spray tip, 0.015 in. orifice, 6 in. fan width
Graco · Tools & Workshop Consumables · Spray Tips
Graco LP315 RAC X LP (low pressure) SwitchTip, a reversible (clog-clearing) airless spray tip, part number LP315, with a 0.015 in. (0.38 mm) orifice and a 6 in. (203 mm) spray fan width. Maximum working pressure 4050 psi (280 bar), maximum flow rate 0.24 gpm. The LP tip number 315 encodes the size: the first digit (3) doubled gives the 6 in. fan width and the last two digits (15) give the 0.015 in. orifice. The LP design atomises at a lower pressure than a standard RAC X tip of the same orifice. For use with RAC X HandTite Tip Guard.
Specifications
- Part number
- LP315
- HS code
- 8424.90
- Pressure rating
- 4050 psi (280 bar)
Compatibility
RAC X LP SwitchTip — fits the Graco RAC X tip guard (RAC X HandTite Tip Guard) on RAC X-equipped airless sprayers. The reversible design lets the tip be rotated to clear a clog without removing it. Tip size is selected by material and required fan width; the LP series lowers the pressure needed for a clean spray pattern. Confirm the sprayer and tip guard are RAC X before ordering.
