Graco XP50-HF Hazardous Location Proportioning Pump Package, 4:1 Mix Ratio
Pricing
Request a quote
We reply within 24 hours
Product Description
Graco 573400 XP50-hf Hazardous Location Proportioning Pump Package, 4:1 Mix Ratio, part number 573400. XP50-hf plural-component proportioner, 4:1 mix ratio, 5000 psi (344 bar) maximum working pressure, 3.8 GPM maximum flow, +/- 5% mix accuracy. Compatible material: Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents. All values read from the Graco product page (573400 on graco.com).
Technical Specifications
- Brand
- Graco Series: XP50-hf Product type: Plural Component Part number: 573400 Type: Plural Component Sprayer Component type: Plural-Component Configuration: Bare (Motors and Lowers Only) Applicator type: Automatic Airless, Manual Airless material application: Coatings, Paints, Primers Power source: Air Measuring type: Fixed Mechanical Positive Displacement Flush type: Solvent Number of tanks: 0 Number of catalysts: 1 Number of resin colors: 1 Number of reducers: 0 Compatible material: Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents Mix ratio: 4:1 Mix accuracy: +/- 5 % Maximum working pressure: 5000 psi (344 bar) Maximum spray pressure: 5000 psi (344 bar) Maximum air inlet pressure: 100 psi (6.9 bar) Maximum flow rate: 3.8 GPM (14.38 L/min) (14380 cc/min) Maximum cycle rate: 40 CPM Maximum fluid temperature: 160 °F (71 °C) Maximum fluid viscosity: 20000 cP minimum fluid viscosity: 200 cP Maximum hose length: 300 ft (91.4 m) Fluid inlet size: 1-1/4 in NPSM Fluid outlet size: 1/2 in NPT Air inlet size: 1 in NPSM Sound power level: 96 dB(A) Sound pressure level: 86.8 dB(A) Wetted material: Carbon Steel with Electroless Nickel Plating, Plated Carbon Steel, Stainless Steel, Carbide, Acetal, UHMWPE, Nylon, PTFE Solvent Resistant Plastics, Carbon Filled PTFE, Aluminum Overall height: 62 in (1575 mm) Overall width: 35 in (889 mm) Overall depth: 52 in (1321 mm) Weight: 320 lb (145 kg) Includes: Air Motor, Pump Lowers
Standards & Compliance
- Pressure Rating
- 5000 psi (344 bar) max working
- Temperature Range
- up to 160 °F (71 °C) fluid
- HS Code
- 8424.20
Compatibility & Fitment
XP50 is Graco's fixed-ratio plural-component proportioner for high-viscosity protective coatings. 4:1 mix ratio; 5000 psi max working pressure; 3.8 GPM. Confirm mix ratio, material viscosity range and heater configuration match the coating before ordering.
