Graco XP50-HF Proportioning Pump Package without Pump Lowers, Cart, XTR Gun
Pricing
Request a quote
We reply within 24 hours
Product Description
Graco 573000 XP50-hf Proportioning Pump Package without Pump Lowers, Cart, XTR Gun, part number 573000. Graco XP50-hf Proportioning Pump Package without Pump Lowers plural component sprayer. Air power source. 5000 psi maximum working pressure. All values read from the Graco product page (573000 on graco.com).
Technical Specifications
- Brand
- Graco
- Family
- XP50-hf Proportioning Pump Package without Pump Lowers
- Part number
- 573000
- Air Inlet Size (in)
- 1
- Air Inlet Thread Gender
- Male
- Air Inlet Thread Type
- NPSM
- Compatible Material
- Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents
- Fluid Inlet Size (in)
- 1-1/4
- Fluid Inlet Thread Gender
- Male
- Fluid Inlet Thread Type
- NPSM
- Fluid Outlet Size (in)
- 1/2
- Fluid Outlet Thread Gender
- Female
- Fluid Outlet Thread Type
- NPT
- Includes
- Air Motor, Cart, Spray Gun, Supply Hose
- Maximum Air Consumption (SCFM)
- 60 scfm/gpm at 100 psi
- Maximum Air Inlet Pressure (psi)
- 100
- Maximum Cycle Rate (CPM)
- 40
- Maximum Flow Rate (GPM)
- 4
- Maximum Operating Temperature (°F)
- 130
- Maximum Working Pressure (psi)
- 5000
- Overall Depth (in)
- 52
- Overall Height (in)
- 62
- Overall Width (in)
- 35
- Power Source
- Air
- Type
- Plural Component Sprayer
- Weight (lb)
- 320
- Wetted Material
- Carbon Steel with Electroless Nickel Plating, Plated Carbon Steel, Stainless Steel, Carbide, Acetal, UHMWPE, Nylon, PTFE Solvent Resistant Plastics, Carbon Filled PTFE, Aluminum
- Maximum Air Inlet Pressure (bar)
- 6.9
- Maximum Flow Rate (L/min)
- 15.14
- Maximum Operating Temperature (°C)
- 54
- Maximum Working Pressure (bar)
- 344
- Overall Depth (mm)
- 1321
- Overall Height (mm)
- 1575
- Overall Width (mm)
- 889
- Weight (kg)
- 145
Standards & Compliance
- Material
- Carbon Steel with Electroless Nickel Plating, Plated Carbon Steel, Stainless Steel, Carbide, Acetal, UHMWPE, Nylon, PTFE Solvent Resistant Plastics, Carbon Filled PTFE, Aluminum
- Pressure Rating
- 5000 psi max
- Temperature Range
- up to 130 °F
- HS Code
- 8424.20
Compatibility & Fitment
Complete spray system/package. Confirm power source and pump type against the coating and layout before ordering; bundled items are listed under "Includes" in the specifications.
