Fluke 77 IV Digital Multimeter

Fluke digital multimeters are designed to provide precision and accuracy!

Manufacturer part number (MPN)

2727486

Brand

Fluke

Category

Tools

Voltage DC Range

6.000 V – 1000 V

Voltage DC Best accuracy

±(0.3% + 1)

Voltage DC Best resolution

0.1 mV

Voltage AC Range

600.0 mV – 1000V

Voltage AC Best accuracy

±(2.0% + 2)

Voltage AC Best resolution

1.0 mV

Amps AC Range

60.00 mA – 10 A

Amps AC Best accuracy

2.5% + 2

Amps AC Best resolution

0.01 mA

Amps DC Range

60.00 mA – 10A

Amps DC Best accuracy

1.5% + 2

Amps DC Best resolution

0.01 mA

Resistance Range

600.0 Ω – 50 MΩ

Resistance Best accuracy

±(0.5% + 1)

Resistance Best resolution

0.1 Ω

Capacitance Range

1nF – 9,999 μF

Capacitance Best accuracy

±(1.2% + 2)

Capacitance Best resolution

1 nF

Frequency Range

99.99Hz – 99.99kHz

Frequency Best accuracy

±(0.1% + 1)

Frequency Best resolution

0.01 Hz

Safety

ANSI / ISA S82.02.01, CSA C22.2–1010.1, IEC 61010 to 1000 V Measurement Category III, 600 V Measurement Category IV

Certifications

CSA, TÜV (EN61010), Π, (N10140)

Maximum voltage between any terminal and earth ground

1000 V

Surge protection

8 kV peak per IEC 61010

Ω Fuse for mA inputs

440 mA, 1000 V FAST Fuse

Ω Fuse for A inputs

11 A, 1000 V FAST Fuse

Display Digital

6000 counts, updates 4/sec

Display Bar graph

33 segments, updates 32/sec

Display Frequency

10,000 counts

Display Capacitance

1,000 counts

Altitude Operating

2,000 meters

Altitude Storage

12,000 meters

Temperature Operating

-10°C to + 50°C

Temperature Storage

-40°C to + 60°C

Temperature coefficient

0.1 x (specified accuracy / °C ( 28°C)

Relative humidity (maximum non-condensing)

90% to 35°C 75% to 40°C 45% to 50°C

Battery life

400 hours typical (alkaline)

Size (H x W x L)

4.3 x 9 x 18.5 cm

Weight

420 g

HS Code

9030.33
