Festo QSLV2 Multi-distributor double composite BSPP nipple - 8mm, 3/8", QSLV2-3/8-8
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo QSLV2 Multi-distributor double composite BSPP nipple. Insertions C (Technique / Pneumatics / Pneumatic Fittings). Principal data: outer hose diameter 8 mm, thread 3/8", supplier type designation QSLV2-3/8-8. Supplied under manufacturer part number 153216, EAN 4052568032999, HS code 7412.20, country of origin Taiwan.
Technical Specifications
- Size
- Standard
- Nominal size
- 4.3 mm
- Tubing insertion depth
- 18.1 mm
- Type of seal on screwed plug
- Coating
- Mounting position
- Any
- Design
- Push-pull principle
- Size of pack
- 1
- Operating pressure complete temperature range
- -0.095 ... 0.6 MPa (-0.95 ... 6 bar) (-13.775 ... 87 psi)
- Temperature-dependent operating pressure
- -0.095 ... 1.4 MPa (-0.95 ... 14 bar) (-13.775 ... 203 psi)
- Note on operating pressure
- Water: max. 0.6 MPa at 0 - 50 °C
- Operating medium
- Compressed air to ISO 8573-1:2010 [7:-:-]; Water (liquid, ice-free)
- Note on operating and pilot medium
- Lubricated operation possible
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 ... 80 °C
- Nominal torque
- 15.5 Nm
- Tolerance for nominal tightening torque
- ±20%
- Product weight
- 54 g
- Number of outputs
- 2
- Number of supply lines
- 1
- Pneumatic connection, port 1
- Male thread R3/8
- Pneumatic connection, port 2
- For tubing outside diameter of 8 mm
- Colour of release ring
- Blue
- Material housing
- PBT
- Material hollow bolt
- Brass, nickel-plated
- Material release ring
- POM
- Material tubing seal
- NBR
- Material tubing clamp component
- High-alloy stainless steel
- EAN / GTIN
- 4052568032999
- Festo type code
- QSLV2-3/8-8
- Festo order number
- 153216
- Product type
- Insertions C
- Product group
- Pneumatics
- Outer hose diameter
- 8 mm
- Thread
- 3/8"
- Carbon footprint (EPD)
- 0.4425 kg CO2e per pcs
- Country of origin
- Taiwan
- Customs tariff code (EU CN)
- 74122000
- HS code
- 7412.20
- Manufacturer part number
- 153216
Standards & Compliance
- HS Code
- 7412.20
Cross References
- EAN 4052568032999
- MPN 153216
