Festo
Festo LR-1/4-D-7-O-MIDI Pressure regulator
Part number186454EAN / GTIN4052568014704HS code8481.10
Pneumatics
Air Preparation
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Festo LR-1/4-D-7-O-MIDI — Pressure regulator, compressed air preparation. operating pressure 0. 1.6 MPa (0. 16 bar).
Technical Specifications
- Manufacturer part number (MPN)
- 186454
- Type code
- LR-1/4-D-7-O-MIDI
- EAN / GTIN
- 4052568014704
- Product category
- Compressed air preparation
- Lifecycle status
- Phase-out
- Size
- Midi
- Series
- D
- Actuator lock
- Rotary knob with detent
- Mounting position
- Any
- Design
- Directly actuated diaphragm regulator
- Controller function
- Output pressure constant, with primary pressure compensation, with secondary exhausting
- Symbol
- 00991540
- Pressure gauge (ANALOG) or Pressure display (DIGITAL)
- Prepared for G1/4
- Operating pressure
- 0 ... 1.6 MPa (0 ... 16 bar)
- Pressure regulation range
- 0.5 ... 7 bar
- Max. pressure hysteresis
- 0.02 MPa (0.2 bar; 2.9 psi)
- Standard nominal flow rate (standardised to DIN 1343)
- 2200 l/min
- Operating medium
- Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas
- Corrosion resistance class CRC
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Air purity class at output
- Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas
- Media temperature
- -10 ... 60 °C
- Ambient temperature
- -10 ... 60 °C
- Product weight
- 660 g
- Type of mounting
- With accessories
- Pneumatic connection, port 1
- G1/4
- Pneumatic connection, port 2
- G1/4
- Material sub-base
- Die-cast zinc
- Material seals
- NBR
- Material housing
- Die-cast zinc
- Product type
- Air treatment
- Product group
- Pneumatics
- Thread
- 1/4"
- Press Area
- 0.5 to 7 bar
- Carbon footprint (EPD)
- 7.4939 kg CO2e per pcs
- Country of origin
- Hungary
- Customs tariff code (EU CN)
- 84811099
- HS code
- 8481.10
Standards & Compliance
- HS Code
- 8481.10
Cross References
- EAN 4052568014704
- MPN 186454
Product Documentation
Document preview: LR-1/4-D-7-O-MIDI — Festo product documentation
More from Festo
Festo
Festo DZF-18-10-A-P-A Flat cylinder
161237
Festo
Festo CRDSNU-B-40-200-PPS-A-MG-A1 Round cylinder
8073981
Festo
Festo FRC-3/8-D-5M-MIDI-A Service unit
162781
Festo
Festo AEVU-20-15-A-P-A Compact cylinder
156988
Festo
Festo VUVG-L14-T32C-M-G18-P1 Solenoid valve
8033526
Festo
Festo DGST-16-50-PA Mini slide
8085134
Festo
Festo LFMAP-D-MAXI Micro-filter cartridge
162676
Festo
Festo CPE10-3/2-PRS-1/4-7 Manifold block
