Festo LFX-1/2-D-MIDI Activated carbon filter

Festo LFX-1/2-D-MIDI — Activated carbon filter, compressed air preparation. operating pressure 0. 1.6 MPa (0. 16 bar; 0. 232 psi).

Manufacturer part number (MPN)

532783

Type code

LFX-1/2-D-MIDI

EAN / GTIN

4052568165499

Product category

Compressed air preparation

Lifecycle status

Phase-out

Size

Midi

Series

D

Mounting position

Vertical +/-5°

Design

Activated carbon filter, Fibre filter

Bowl guard

Metal bowl guard

Symbol

00991519

Operating pressure

0 ... 1.6 MPa (0 ... 16 bar; 0 ... 232 psi)

Recommended max. nominal flow rate

900 l/min

Max. standard flow rate for clean air class

900 l/min

Operating medium

Inert gas

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Storage temperature

-10 ... 60 °C

Air purity class at output

Compressed air according to ISO 8573-1:2010 [1:4:1], Inert gas

Media temperature

5 ... 30 °C

Residual oil content

0.003 mg/m³

Ambient temperature

-10 ... 60 °C

Product weight

816 g

Type of mounting

With mounting bracket

Pneumatic connection

G1/2

Pneumatic connection, port 1

Sub-base, G1/2

Pneumatic connection, port 2

Sub-base, G1/2

Material filter

Activated carbon, Fabric

Material housing

Die-cast zinc

Material bowl

Makrolon®

Product type

Air treatment

Product group

Pneumatics

Thread

1/2"

Carbon footprint (EPD)

6.0538 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84213925

HS code

8421.39

HS Code

8421.39

• EAN 4052568165499
• MPN 532783
