Festo LFMBA-1/8-D-MINI-A Filter combination

Festo LFMBA-1/8-D-MINI-A — Filter combination, compressed air preparation. operating pressure 1.5. 12 bar.

Manufacturer part number (MPN)

162666

Type code

LFMBA-1/8-D-MINI-A

EAN / GTIN

4052568132057

Product category

Compressed air preparation

Lifecycle status

Phase-out

Size

Mini

Series

D

Mounting position

Vertical +/-5°

Grade of filtration

0.01 µm

Filter efficiency

99.9999 %

Condensate drain

Fully automatic

Design

Fibre filter

Max. condensate volume

22 ml

Bowl guard

Metal bowl guard

Symbol

00991551

Operating pressure

1.5 ... 12 bar

Operating medium

Compressed air to ISO 8573-1:2010 [6:8:4], Inert gas

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Air purity class at output

Compressed air to ISO 8573-1:2010 [1:7:2], Inert gas

Media temperature

1.5 ... 60 °C

Residual oil content

0.01 mg/m³

Ambient temperature

-10 ... 60 °C

Product weight

500 g

Type of mounting

With accessories

Pneumatic connection, port 1

G1/8

Pneumatic connection, port 2

G1/8

Material filter

Borosilicate fibre

Material housing

Die-cast zinc

Material bowl

Makrolon®

Product type

Air treatment

Product group

Pneumatics

Thread

1/8"

Filter element

0.01 My

Carbon footprint (EPD)

13.8902 kg CO2e per pcs

Country of origin

Hungary

Customs tariff code (EU CN)

84213925

HS code

8421.39

HS Code

8421.39

• EAN 4052568132057
• MPN 162666
