Festo HEL-1/4-D-MINI On/off valve

Festo HEL-1/4-D-MINI — On/off valve, compressed air preparation. valve function 2/2-way, single solenoid, closed; operating pressure 0.3. 1.6 MPa (3. 16 bar).

Manufacturer part number (MPN)

165077 Type code: HEL-1/4-D-MINI EAN / GTIN: 4052568073671 Product category: Compressed air preparation Lifecycle status: Phase-out Exhaust-air function: Can be throttled Type of actuation: Pneumatic Sealing principle: Soft Mounting position: Any Manual override: None Design: Piston gate valve Type of reset: Mechanical spring Type of piloting: Direct Flow direction: Non-reversible Symbol: 00991513 Valve function: 2/2-way, single solenoid, closed Operating pressure: 0.3 ... 1.6 MPa (3 ... 16 bar) b value: 0.41 C value: 7.1 l/sbar Standard nominal flow rate (standardised to DIN 1343): 1500 l/min Operating medium: Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas Corrosion resistance class CRC: 2 - Moderate corrosion stress LABS (PWIS) conformity: VDMA24364-B1/B2-L Air purity class at output: Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas Media temperature: -10 ... 60 °C Ambient temperature: -10 ... 60 °C Product weight: 126 g Type of mounting: Inline installation Pneumatic connection, port 1: G1/4 Pneumatic connection, port 2: G1/4 material seals: NBR material housing: Die-cast aluminium Product type: Air treatment Product group: Pneumatics Thread: 1/4" Activation: pneumatic Return: Spring Series: HEL Carbon footprint (EPD): 1.7872 kg CO2e per pcs Country of origin: Hungary Customs tariff code (EU CN): 84812090 HS code: 8481.20

HS Code

8481.20

• EAN 4052568073671
• MPN 165077
