Festo DNC-63-40-PPV ISO cylinder

Festo DNC-63-40-PPV — ISO cylinder, pneumatic cylinders. stroke 40 mm; piston diameter 63 mm; operating pressure 0.06. 1.2 MPa (0.6. 12 bar).

Manufacturer part number (MPN)

163416

Type code

DNC-63-40-PPV

EAN / GTIN

4052568134341

Product category

Pneumatic cylinders

Lifecycle status

Phase-out

Stroke

40 mm

Piston diameter

63 mm

Piston rod thread

M16x1.5

Cushioning

Pneumatic cushioning, adjustable at both ends

Mounting position

Any

Conforms to standard

ISO 15552

Piston-rod end

Male thread

Design

Piston, Piston rod, Profile barrel

Position detection

None

Symbol

00991232

Variants

Piston rod at one end

Operating pressure

0.06 ... 1.2 MPa (0.6 ... 12 bar)

Mode of operation

Double-acting

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Ambient temperature

-20 ... 80 °C

Impact energy in end positions

0.5 J

Cushioning length

22 mm

Theoretical force at 0.6 MPa (6 bar, 87 psi), return strok

1682 N

Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stro

1870 N

Moving mass for 0 mm stroke

663 g

Additional moving mass per 10 mm stroke

25 g

Basic weight for 0 mm stroke

1709 g

Additional weight per 10 mm stroke

73 g

Type of mounting

With female thread, with accessories

Pneumatic connection

G3/8

Material cover

Die-cast aluminium, coated

Material seals

TPE-U(PU)

Material piston rod

High-alloy steel

Material cylinder barrel

Wrought aluminium alloy, Smooth-anodised

Product type

Pneumatic ISO Air Cylinder

Product group

Pneumatics

Port Size

G3/8"

Carbon footprint (EPD)

40.9858 kg CO2e per pcs

Country of origin

Germany

Customs tariff code (EU CN)

84123100

HS code

8412.31

HS Code

8412.31

• EAN 4052568134341
• MPN 163416
