Festo CLR-63-50-G-P-A Linear/swivel clamp

Festo CLR-63-50-G-P-A — Linear/swivel clamp, swing clamp cylinders. piston diameter 63 mm; operating pressure 2. 10 bar.

Manufacturer part number (MPN)

535470

Type code

CLR-63-50-G-P-A

EAN / GTIN

4052568168988

Product category

Swing clamp cylinders

Total stroke

73 mm

Piston diameter

63 mm

Piston rod thread

M10

Clamping stroke

50 mm

Cushioning

Elastic cushioning rings/plates at both ends

Mounting position

Any

Design

Piston, Piston rod, Cylinder barrel

Position detection

Via proximity switch

Swivel direction

Straight

Symbol

00991217

Operating pressure

2 ... 10 bar

Mode of operation

Double-acting

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B2-L

Ambient temperature

-10 ... 80 °C

Effective clamping force at 0.2 MPa (2 bar, 29 psi)

441 N

Effective clamping force at 0.4 MPa (4 bar, 58 psi)

823 N

Effective clamping force at 0.6 MPa (6 bar, 87 psi)

1386 N

Max. tightening torque Clamping finger screw

47 Nm

Theoretical clamping force at 0.6 MPa (6 bar, 87 psi)

1682 N

Product weight

2635 g

Type of mounting

With through-hole, with female thread, with accessories

Pneumatic connection

G1/8

Material collar screws

Steel, Galvanised

Material cover

Wrought aluminium alloy, coated

Material seals

NBR, TPE-U(PU)

Material housing

Smooth-anodised

Material piston rod

High-alloy stainless steel

Material cylinder barrel

Wrought aluminium alloy, Smooth-anodised

Product type

Pneumatic ISO compact air cylinders

Product group

Pneumatics

Port Size

G1/8

Carbon footprint (EPD)

53.4231 kg CO2e per pcs

Country of origin

China

Customs tariff code (EU CN)

84799070

HS code

8479.90

HS Code

8479.90

• EAN 4052568168988
• MPN 535470
