Product Description
Elpress crimping die set. Part of the Elpress crimping tool system. Dies, punches and crimp heads are matched by tool system (13-ton V1300, 25-ton V250) and by conductor cross-section; select to match terminal type and area.
Technical Specifications
- Manufacturer part number (MPN)
- 13DCB11
- EAN / GTIN
- 7393487026094
- Sales unit
- pcs
- Article number
- 5303-100700
- Type designation
- 13DCB11
- W (mm)
- 10
- L (mm)
- 11
- h1 (mm)
- 4.33
- h2 (mm)
- 1.4
- Crimp geometries
- Dual
- Number of crimps
- 1
- AWG/MCM Cu
- 4 AWG
- mm² KR/KS, KRF/KSF
- 25
- Application
- Pipe cable lug and connectors
- Compression shape
- Hexagon
- Cross section, Min (mm²)
- 25
- Cross section, Max (mm²)
- 25
- AWG-range, Min
- 4
- AWG-range, Max
- 4
- Pieces per pack
- 1
- Net weight (kg)
- 0.465
- Height Pack (mm)
- 41
- Depth Pack (mm)
- 87
- Width Pack (mm)
- 68
- Cross section
- 25 mm²
- AWG-range
- 4
- Country of origin
- Sweden
Standards & Compliance
- HS Code
- 8207.30
Cross References
- EAN 7393487026094
- SAP 1000417221
- Code 8499664
Product Documentation
Document preview: Elpress Crimping die set (13DCB11) — Specification sheet
