Elpress 5204-010300 PVL130S Battery-Hydraulic Crimping Tool 0.25-50 mm²

Elpress PVL130S is a battery-hydraulic crimping tool for cable lugs and connectors from 0.25 to 50 mm² (24 to 1/0 AWG). Universal exchangeable inserts, 15 kN compression force, automatic return and mechanical locking. Powered by a 10.8 V, 2.0 Ah Li-Ion battery; supplied in a plastic case.

Manufacturer part number (MPN)

5204-010300

EAN / GTIN

7393487059825

Sales unit

pcs

Article number

5204-010300

Type designation

PVL130S

Delivery box

Plastic case

Working temperature, Min (°C)

-10

Working temperature, Max (°C)

40

Crimp geometries

Tab, Oval, Roll, Trapezoid, W

Battery

10,8V, 2,0Ah Li-Ion

Crimp time (s)

approx. 2, depending on the material

AWG/MCM Cu

24 - 1/0 AWG

mm² Cu

0,25-50

Suitable for

Cable lugs and connectors

Construction/operation

Accumulator-hydraulic

Compression shape

Universal (exchangeable inserts)

With locking device (for mechanical tools)

Yes

Cross section, Min (mm²)

0.25

Cross section, Max (mm²)

50

AWG-range, Min

24

With automatic return

Yes

Inserts exchangeable

Yes

Number of included inserts

1

Compression force, Min (kN)

15

Compression force, Max (kN)

15

Length (mm)

58

Pieces per pack

1

Net weight (kg)

1.5

Height Pack (mm)

100

Depth Pack (mm)

300

Width Pack (mm)

310

Cross section

0.14–50 mm²

Country of origin

Germany

HS Code

8203.20

• EAN 7393487059825
• SAP 1000795623
• Code 81417392
