Elpress AS1625 Aluminium Compression Through Connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Elpress AS1625 — aluminium compression through connector (splice) with internal partition for jointing small-section aluminium conductors. Made from solid aluminium (Al 99.7%); the central partition acts as a cable stop for even conductor insertion. Tested to IEC 61238-1 within the Elpress crimp system.
Technical Specifications
- Type
- Aluminium compression through connector with partition
- Material
- Solid aluminium (Al 99.7%)
- Feature
- Internal partition (central cable stop)
- Crimp system
- System Elpress, tested to IEC 61238-1
- Manufacturer part number (MPN)
- AS1625
- EAN / GTIN
- 7393487049246
- Sales unit
- pcs
- Package quantity
- 50 pcs
- HS code
- 8536.90
- Article number
- 7313-448000
- Type designation
- AS1625
- d (mm)
- 6.2
- L (mm)
- 35
- s (mm) - strip length
- 18
- AWG/MCM Stranded Al
- 6 - 4 AWG
- mm² Stranded Al
- 16-25
- Oil stop/centre bar
- Yes
- Cross section shape
- Round
- Nominal cross section aluminium, RM/SM, Max (mm²)
- 25
- Pieces per pack
- 50
- Net weight (kg)
- 0.007
- Height Pack (mm)
- 82
- Depth Pack (mm)
- 87
- Width Pack (mm)
- 68
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7393487049246
- SAP 1000679205
- Code 8576525
Product Documentation
