Elpress KRF70-12 Copper Tube Cable Lug 70 mm² M12
Pricing
Request a quote
We reply within 24 hours
Product Description
Elpress KRF70-12 — compression (crimp) tube cable lug for terminating 70 mm² copper conductor onto an M12 stud. Barrel dimensioned for stranded (IEC 60228 Class 2) and flexible (Class 5) copper conductors, with a cable inspection hole for correct conductor insertion. Formed from 99.95% electrolytic copper, tin-plated (Cu/Sn). Crimped with matching Elpress dies to produce a gas-tight, low-resistance connection tested to IEC 61238-1. Carries DNV type approval and UL listing (File E205350) within the tested Elpress crimp system. Applied in low-voltage power distribution, switchboards, motor terminations and marine and offshore installations.
Technical Specifications
- Type
- Compression (crimp) tube cable lug
- Conductor cross-section
- 70 mm²
- Stud / bolt hole
- M12
- Conductor class
- Stranded (IEC 60228 Cl.2) & flexible (Cl.5)
- Material
- Electrolytic copper 99.95%, tin-plated (Cu/Sn)
- Feature
- Cable inspection hole
- Crimp system
- System Elpress, tested to IEC 61238-1
- Approvals
- DNV type approval, UL File E205350
- Manufacturer part number (MPN)
- KRF70-12
- EAN / GTIN
- 7393487006126
- Sales unit
- pcs
- Package quantity
- 50 pcs
- HS code
- 8536.90
- Article number
- 7301-014200
- Type designation
- KRF70-12
- W (mm)
- 25
- N (mm)
- 12
- N1 (mm)
- 13
- P (mm)
- 25
- f (mm)
- 1
- d (mm)
- 13
- L (mm)
- 58
- t (mm) - palm thickness
- 3.9
- s (mm) - strip length
- 22
- Screw
- M12
- Inspection hole
- Yes
- AWG/MCM Cu
- 2/0 AWG
- mm² Cu
- 70
- Surface protection
- Tin plated
- Connecting angle
- 180° (horizontal)
- Flange shape
- Ring shape
- Conductor category
- Several
- Number of mounting holes
- 1
- Bolt dimension metric (M)
- 12
- With sight-hole
- Yes
- AWG size
- 00
- Pieces per pack
- 50
- Net weight (kg)
- 0.044
- Height Pack (mm)
- 145
- Depth Pack (mm)
- 180
- Width Pack (mm)
- 87
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7393487006126
- SAP 1000000188
- Code 816544
Product Documentation
More from Elpress
Elpress
Elpress KRF16-8 Copper Tube Cable Lug 16 mm² M8
Elpress
Elpress AKK150-16 Aluminium-Copper Bimetallic Compression Cable Lug 150 mm² M16
Elpress
Elpress KRF16-10 Copper Tube Cable Lug 16 mm² M10
Elpress
Elpress KRF120-10 Copper Tube Cable Lug 120 mm² M10
Elpress
Elpress KS4 Copper Compression Through Connector 4 mm²
Elpress
Elpress AKK50-12 Aluminium-Copper Bimetallic Compression Cable Lug 50 mm² M12
Elpress
Elpress KR10-12 Copper Tube Cable Lug 10 mm² M12
Elpress
Elpress KSF240A Copper Compression Through Connector 240 mm²
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy KRF70-12?
- KRF70-12 can be ordered from cballast.com as a Elpress catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Elpress product?
- The manufacturer part number is KRF70-12.
- What is the HS code for KRF70-12?
- The customs tariff (HS) code for KRF70-12 is 8536.90.
- Who manufactures KRF70-12?
- KRF70-12 is a Elpress product in the Electrical Components range.
- Is a datasheet available for KRF70-12?
- Yes — the KRF70-12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for KRF70-12?
- The minimum order quantity is 1.
- Is KRF70-12 available?
- Yes — KRF70-12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
