Elpress C16-25 C-Sleeve
Pricing
Request a quote
We reply within 24 hours
Overview
Elpress C16-25 C-Sleeve (part number 7309-300500) is listed under Electrical Components / Cable Lugs. Sales unit: pcs; Package quantity: 100 pcs; Type designation: C16-25; a (mm): 22; b (mm): 16; c (mm): 12.
Technical Specifications
- Manufacturer part number (MPN)
- 7309-300500
- EAN / GTIN
- 7393487062320
- Sales unit
- pcs
- Package quantity
- 100 pcs
- Article number
- 7309-300500
- Type designation
- C16-25
- a (mm)
- 22
- b (mm)
- 16
- c (mm)
- 12
- mm² C-sleeve Cu Range, Min
- 30
- mm² C-sleeve Cu Range, Max
- 50
- Side feed, Cu (mm²)
- 16/16-25, 25/(2*2,5)-25
- Front feed, Cu (mm²)
- 16-25/16-25, 25/(2*2,5)-10
- Side feed, Cu (AWG/MCM)
- #6/#6-4, #4/(2*#14)-#4
- Front feed, Cu (AWG/MCM)
- #6-4/#6-4-, #4/(2*#14)-#8
- Surface protection
- Tin plated
- Material
- Copper
- Pieces per pack
- 100
- Net weight (kg)
- 0.0218
- Height Pack (mm)
- 81
- Depth Pack (mm)
- 84
- Width Pack (mm)
- 147
- Cross section through-wiring core
- 25–35 mm²
- Cross section branch core
- 6–25 mm²
- Length
- 22 mm
- Suitable for solid conductors
- Yes
- Country of origin
- Sweden
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7393487062320
- SAP 1200149316
- Code 82044012
Product Documentation
