Elis Elektro
Straight Nipple SEM/M25 for NW 22 Conduit
Part number1212675EAN / GTIN7070613001711HS code7412.20
Electrical Components
Steel Conduit & Fittings
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Elis Elektro 1212675 straight nipple (conduit fitting) SEM/M25 for NW 22 flexible conduit.
Technical Specifications
- Manufacturer part number (MPN)
- 1212675
- Sales unit
- pcs
- Package quantity
- 25 pcs
- EL number
- 1212675
- EAN / GTIN
- 7070613001711
- ETIM class
- EC001178 - Screw connection for protective plastic hose
- CE marked
- Yes
- REACH relevant
- No
- Country of origin
- Germany
- HS code
- 74122000
- Base unit
- pcs
- Price unit
- pcs
- Product height
- 48 mm
- Product width
- 40.5 mm
- Product length / depth
- 40.5 mm
- Net weight
- 20 g
- Product volume
- 0.078732 dm³
- Price units per base unit
- 1
- Total height (mm)
- 48
- Total length (mm)
- 40.5
- Thread length (mm)
- 13
- Lowest inner diameter hose (mm)
- 25
- Max. outer diameter hose (mm)
- 40.5
- Working temperature (°C)
- -40 to 120
- With integrated holder
- Yes
- Approved in combination with protective conduit according to EN 61386-23
- Yes
- One-piece
- No
- Revolving thread
- No
- Approved in combination with protective conduit UR
- No
- Colour
- Black
- Model
- Straight
- Type of connection
- Snap connection
- Construction type
- External thread
- Operating temperature
- -40–120 °C
- Degree of protection (IP)
- IP50
- Thread connection size
- M25 x 1.5
- Material screw gland
- Polyamide (PA)
Standards & Compliance
- HS Code
- 7412.20
Cross References
- 7070613001711
Product Documentation
Document preview: Nipple Rett SEM/M25 for NW 22 (1212675) — Data Sheet (OEM, Norwegian)
