Eaton
Undervoltagestrigger 208-240V (NZM4-XU208-240AC)
Part numberNZM4-XU208-240ACEAN / GTIN4015082661939HS code8538.90
Electrical Components
Circuit Breaker Accessories
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Undervoltagestrigger 208-240V (NZM4-XU208-240AC) is listed under Electrical Components / Circuit Breaker Accessories. HS code: 8538.90.
Technical Specifications
- Manufacturer part number (MPN)
- NZM4-XU208-240AC EAN / GTIN: 4015082661939 Sales unit: pcs Eaton catalogue number: 266193 Depth: 107 mm Height: 51 mm Width: 64 mm Weight: 0.257 kg Compliances: UL/CSA; IEC; RoHS conform Certifications: UL489; UL (Category Control Number DIHS); IEC60947; UL (File No. E140305); CSA (Class No. 1437-01); CSA-C22.2 No. 5-09; CSA (File No. 22086); CE marking; UL listed; CSA certified Frame: NZM4 Suitable for: Off-load switch Type: Undervoltage release Used with: NZM4(-4), N(S)4(-4) Drop-out voltage of undervoltage release AC/DC - max: 0.7 x Us Drop-out voltage of undervoltage release AC/DC - min: 0.35 x Us Electric connection type: Screw connection minimum command time - max: 15 ms minimum command time - min: 10 ms Pick-up power consumption at AC (undervoltage release): 3.6 VA Pick-up power consumption at DC (undervoltage release): 2.5 W Power consumption: 3.6 VA (AC); 2.5 W (DC) Rated control supply voltage: 208 - 240 V 50/60 Hz Rated control supply voltage (Us) at AC, 50 Hz - max: 240 V Rated control supply voltage (Us) at AC, 50 Hz - min: 208 V Rated control supply voltage (Us) at AC, 60 Hz - max: 240 V Rated control supply voltage (Us) at AC, 60 Hz - min: 208 V Rated control voltage (relay contacts): 208 V AC; 240 V AC Reaction time: 23 ms Voltage tolerance - max: 1.1 Voltage tolerance - min: 0.85 Voltage type: AC Connection type: With bolt connection Number of contacts (change-over contacts): 0 Number of contacts (normally closed contacts): 0 Number of contacts (normally open contacts): 0 Delayed: No Suitable for off-load switch: Yes Suitable for overload relay: No Type of electric connection: Screw connection Rated control supply voltage AC 50 Hz: 208–240 V Rated control supply voltage AC 60 Hz: 208–240 V Suitable for motor safety switch: No Suitable for power circuit breaker: No Voltage type for actuating: AC Country of origin: Romania
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015082661939
- SAP 1000069068
- Code 8558280
Product Documentation
Document preview: UNDERVOLTAGESTRIGGER 208-240V (NZM4-XU208-240AC) — Specification Data Sheet (OEM)
More from Eaton
Eaton
Complete Indicator Light, Front Mount, Red LED
M22-L-R-LED-BVP
Eaton
Eaton 9PX 2200I RT2U
9PX2200IRT2U
Eaton
Earth-fault RCD 16A 3P+N/D A 30MA
mRB6-16/3N/D/003-A
Eaton
Terminal 4 poles 125A (BPZ-KB-8/125)
Eaton
Eaton PLSM-OV63/2 Miniature Circuit Breaker — 2P, OV, 63 A, 10 kA
Eaton
Uninterruptible UPS. 6000VA/ 5400W
9SX6KI
Eaton
Eaton NZMN1-4-A63 Molded-Case Circuit Breaker 4-Pole 63A 50KA
Eaton
Siren and flashing light (640025FULL-0061X)
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy NZM4-XU208-240AC?
- NZM4-XU208-240AC can be ordered from cballast.com as a Eaton catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Eaton product?
- The manufacturer part number is NZM4-XU208-240AC.
- What is the HS code for NZM4-XU208-240AC?
- The customs tariff (HS) code for NZM4-XU208-240AC is 8538.90.
- Who manufactures NZM4-XU208-240AC?
- NZM4-XU208-240AC is a Eaton product in the Electrical Components range.
- Is a datasheet available for NZM4-XU208-240AC?
- Yes — the NZM4-XU208-240AC datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for NZM4-XU208-240AC?
- The minimum order quantity is 1.
- Is NZM4-XU208-240AC available?
- Yes — NZM4-XU208-240AC is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
