Eaton
Motor Drive
Part numberNZM3-XR208-240ACEAN / GTIN4015082598501HS code8538.90
Electrical Components
Circuit Breaker Accessories
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton NZM3-XR208-240AC Motor Drive 230VAC.
Technical Specifications
- Manufacturer part number (MPN)
- NZM3-XR208-240AC
- EAN / GTIN
- 4015082598501
- Sales unit
- pcs
- Eaton catalogue number
- 259850
- Depth
- 170 mm
- Height
- 140 mm
- Width
- 140 mm
- Weight
- 3.155 kg
- Compliances
- UL/CSA; IEC; RoHS conform
- Certifications
- CSA (File No. 22086); CE marking; CSA (Class No. 1437-01); UL (File No. E140305); UL489; IEC60947; UL listed; CSA certified; CSA-C22.2 No. 5-09; UL (Category Control Number DIHS)
- Frame
- NZM3
- Number of poles
- Three-pole/Four-pole
- Special features
- Cannot be combined with switch-disconnector PN... M22-CK11(20/02) dual auxiliary switch cannot be combined with NZM3-XR… remote operator
- Type
- Accessory Remote operator, can be synchronized
- Used with
- NZM3(-4); N(S)3(-4)
- Breaking time
- 1000 ms
- Closing delay
- 80 ms
- Number of operations per hour - max
- 60
- Operating voltage - max
- 1.1 x Us
- Operating voltage - min
- 0.85 x Us
- Power consumption
- 350 VA (110 - 130 V AC)
- Rated control supply voltage (Us) at AC, 50 Hz - max
- 240 V
- Rated control supply voltage (Us) at AC, 50 Hz - min
- 208 V
- Rated control supply voltage (Us) at AC, 60 Hz - max
- 240 V
- Rated control supply voltage (Us) at AC, 60 Hz - min
- 208 V
- Rated operating frequency
- 50 Hz
- Signal duration of remote operator at switch off - min
- 250 ms
- Signal duration of remote operator at switch on - min
- 30 ms
- Voltage rating
- 208 - 240 V 50/60 Hz
- Voltage tolerance - max
- 1.1
- Voltage tolerance - min
- 0.85
- Voltage type
- AC
- Lifespan, mechanical
- 15000 operations
- Switch drive type
- Motor drive
- Terminal capacity (solid/flexible conductor)
- 18 - 14 AWG; 0.75 mm² - 2.5 mm² with ferrule
- Rated control supply voltage AC 50 Hz
- 208–240 V
- Rated control supply voltage AC 60 Hz
- 208–240 V
- Type of switch drive
- Motor drive
- Voltage type for actuating
- AC
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015082598501
- SAP 1000000738
- Code 816761
Product Documentation
Document preview: MOTOR DRIVE — Specification Data Sheet (OEM)
