Pressure Switch 0,1-4,5 BAR 1P 1V

Eaton MCS4 1-pole (1 changeover contact)pressure switch 1-pole.

Manufacturer part number (MPN)

MCS4 EAN / GTIN: 4015080197119 Sales unit: pcs Eaton catalogue number: 019711 Depth: 96 mm Height: 111 mm Width: 60 mm Weight: 0.383 kg Certifications: IEC/EN 60947-5-1 Mounting position: Vertical and 90° in all directions Shock resistance: 10 g, Mechanical, according to IEC/EN 60068-2-27, Half-sinusoidal shock 20 ms Vibration resistance: 36 Hz, Amplitude 1 mm, (IEC/EN 60068-2-6) Ambient operating temperature - max: 70 °C Ambient operating temperature - min: -25 °C Climatic proofing: Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclic, to IEC 60068-2-30 Environmental conditions: Compliant to 2014/35/EC, 2014/30/EC and EN 60947-5-1. Accordingly, the user must review it separately for the specific application at hand. Number of auxiliary contacts (change-over contacts): 1 Number of auxiliary contacts (normally closed contacts): 0 Number of auxiliary contacts (normally open contacts): 0 Rated frequency - max: 50 Hz Rated insulation voltage (Ui): 400 V Rated operational current (Ie): 2 A at DC-13, 24 V; 2 A at AC-15, 230 V, 50/60Hz; 0.25 A at DC-13, 110 V Rated operational voltage (Ue) at AC - max: 230 V Rated operational voltage (Ue) at DC - max: 110 V Electric connection type: Screw connection Features: Variable switching differential Bursting pressure: 90 bar Connection: Inner thread gas cylindrical (BSPP) Connection type: Tunnel terminal Degree of protection: IP65; NEMA Other Lifespan, electrical: 1,000,000 Operations Operating frequency: 1500 Operations/h Operating pressure - max: 7000 hPa Overvoltage category: III Pollution degree: 3 Product category: Pressure switches Rated impulse withstand voltage (Uimp): 4000 V AC Suitable as: 2-point controller; Guard Test pressure: 32 bar Short-circuit protection: PKZM0-6,3, Fuseless Short-circuit protection rating: Max. 10 A gG/gL, Fuse, Contacts Screw size: M3, Terminal screw Terminal capacity (flexible with ferrule): 1 x (0.5 - 1.5) mm², ferrules to DIN 46228 Terminal capacity (solid): 2 x (0.75 - 1.5) mm²; 1 x (0.75 - 2.5) mm² Tightening torque: 0.5 Nm, Screw terminals Number of poles: 1P With display: No With manual on/off switch: No Max. operation pressure: 7000 hPa Number of auxiliary contacts as change-over contact: 1 Type of electric connection: Screw connection Explosion-proof: No Switch off pressure: 0–4.5 bar Rated voltage Ue at AC 50 Hz: 0–230 V Rated voltage Ue at AC 60 Hz: 0–230 V Rated voltage Ue at DC: 0–110 V Engaging pressure: 0–4.2 bar Electronic version: No Suitable as 2-point controller: Yes Suitable as limiter: No Suitable as guard: Yes Max. test pressure: 32 bar Medium temperature: -25–80 °C With hand operation: No Max. operating pressure: 7000 hPa Country of origin: Hungary

HS Code

8536.50

• EAN 4015080197119
• SAP 1000049691
• Code 8813058
