Eaton
Complete PUSH-Button RED 1TO
Part numberM22-D-R-X0/K01EAN / GTIN4015082165109HS code8536.50
Control & Automation
Pushbuttons & Pilot Lights
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Complete PUSH-Button RED 1TO (part number M22-D-R-X0/K01) is listed under Control & Automation / Pushbuttons & Pilot Lights. Sales unit: pcs; Package quantity: 5 pcs; Eaton catalogue number: 216510; Depth: 70 mm; Height: 30 mm; Width: 30 mm.
Technical Specifications
- Manufacturer part number (MPN)
- M22-D-R-X0/K01
- EAN / GTIN
- 4015082165109
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Eaton catalogue number
- 216510
- Depth
- 70 mm
- Height
- 30 mm
- Width
- 30 mm
- Weight
- 0.026 kg
- Certifications
- CE; IEC/EN 60947-5; UL 508; VDE 0660; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; UL; UL Category Control No.: NKCR; CSA Class No.: 3211-03; IEC/EN 60947; UL File No.: E29184; CSA; CSA File No.: 012528; DNV; GL; LR
- Catalog Notes
- Contacts with safety function, by positive opening to IEC/EN 60947-5-1
- Actuating force
- 5 N
- Actuator color
- Red
- Actuator diameter
- 29.7 mm
- Actuator function
- Spring-return; Momentary
- Actuator travel and actuation force (DIN EN 60947-5-1)
- 4.8 mm
- Bezel color
- Chrome
- Bezel material
- Plastic
- Design
- Flat; Classical
- Electric connection type
- Screw connection
- Features
- Positive opening
- Fitted with
- Front ring
- Inscription
- Inscribed
- Knob travel
- 5.7 mm
- Lens type
- Round
- Number of command positions
- 1
- Ambient operating temperature - max
- 70 °C
- Ambient operating temperature - min
- -25 °C
- Climatic proofing
- Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclic, to IEC 60068-2-30
- Connection to SmartWire-DT
- No
- Heat dissipation per pole, current-dependent Pvid
- 0.11 W
- Rated operational current for specified heat dissipation (In)
- 6 A
- Degree of protection
- NEMA 4X, 13; IP67/IP69K
- Lifespan, mechanical
- 1,000,000 Operations (AC operated)
- Mounting position
- As required
- Opening diameter
- 22.5 mm
- Operating frequency
- 1800 Operations/h
- Overvoltage category
- III
- Pollution degree
- 3
- Product category
- RMQ-Titan
- Size
- Front dimensions: 22 x 22 mm
- Type
- Pushbutton actuator
- Rated conditional short-circuit current (Iq)
- 1 kA
- Hole diameter
- 22 mm
- Colour button
- Red
- Suitable for lighting
- No
- Spring-return
- Yes
- Type of button
- Flat
- Colour front ring
- Chrome
- Type of electric connection
- Screw connection
- Material front ring
- Plastic
- With front ring
- Yes
- Transparent
- No
- Construction type lens
- Round
- Switching function latching
- No
- Number of contacts as normally closed contact
- 1
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 4015082165109
- SAP 1000058070
- Code 8867812
Product Documentation
Document preview: Complete PUSH-Button RED 1TO (M22-D-R-X0/K01) — Specification Data Sheet (OEM)
