Product Description
The Eaton E76-CLRMKP-M12 is a colour-sensing reflected-light photoelectric sensor with three normally-open PNP outputs and short-circuit protection, connected via an 8-pole M12 plug. Rated sensing distance is 450 mm with a 0.65 ms response time and 770 Hz switching frequency, in a 50 x 50 x 25 mm plastic housing at IP67. Typical use is on packaging and assembly lines to sort or verify parts by colour.
Technical Specifications
- Manufacturer part number (MPN)
- E76-CLRMKP-M12
- EAN / GTIN
- 4015081643035
- HS code
- 8536.90
- Sales unit
- pcs
- Eaton catalogue number
- 166927
- Depth
- 25 mm
- Height
- 50 mm
- Width
- 50 mm
- Weight
- 0.43 kg
- Certifications
- UL File No.: E166051; UL; CSA File No.: UL report applies to both US and Canada; UL Category Control No.: NRKH, NRKH7; CE; UL 508; IEC/EN 60947-5-2; Certified by UL for use in Canada; CSA-C22.2 No. 14
- Type
- Optical sensors
- Electric connection type
- Plug-in connection
- Enclosure material
- Plastic
- Enclosure type
- Cuboid
- Functions
- Color sensing; Short-circuit protection; Reflected-light beam
- Voltage type
- DC
- Wire size
- 0
- Lamp type
- Other
- Output
- 3 NO PNP Outputs
- Connection type
- Plug-in connection M12 x 1; 8 conductor
- Fiber optics core material
- Other
- Cable sheath material
- Other
- Light type
- White light; Other
- Degree of protection
- IP67; NEMA 4X
- LED indicator
- Status indication of Switching state: Yellow LED
- Switch function type
- Normally open contact (NO)
- Laser protection class
- Other
- Operation agent-safety class
- Safety class 2
- Shock resistance
- 30 g, Mechanical, Shock duration 11 ms
- Optical surface material
- Glass
- Output current (mA) - max
- 100 mA
- Rated switching distance (Sn)
- 450 mm
- Sensor height
- 50 mm
- Sensor length
- 50 mm
- Voltage rating - max
- 30 V
- Switching frequency
- 770 Hz
- Switching output type
- PNP
- Vibration resistance
- 10 - 55 Hz, Amplitude 0.5 mm; According to IEC/EN 60068-2-6
- Width sensor
- 25 mm
- Product category
- E76 IntelliView Series
- Response time
- 0.65 ms
- Ambient operating temperature - max
- 55 °C
- Ambient operating temperature - min
- -10 °C
- Ambient storage temperature - max
- 70 °C
- Ambient storage temperature - min
- -20 °C
- Number of contact energized outputs with signalling function
- 0
- Number of outputs (semiconductor with signaling function)
- 3
- Operating distance - max
- 45 mm
- Operating temperature - max
- 55 °C
- Operating temperature - min
- -10 °C
- Adjustment type
- Other
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4015081643035
- SAP 1200607034
- Code 82994673
