1NO/1NC 24V50 (Z-S24/So)

Eaton Z-S24/SO 1NO/1NC 24V50.

Manufacturer part number (MPN)

Z-S24/SO

EAN / GTIN

4015082655396

Sales unit

pcs

Package quantity

2 pcs

Eaton catalogue number

265539

Depth

80 mm

Height

70 mm

Width

17.5 mm

Weight

0.136 kg

Compliances

RoHS conform

Number of poles

Two-pole

Mounting method

DIN rail

Control voltage 1 type

AC

Ambient operating temperature - max

45 °C

Ambient operating temperature - min

-20 °C

Control voltage 1 - max

24 V

Control voltage 1 - min

24 V

Control voltage 2 - max

12 V

Control voltage 2 - min

12 V

Frequency control voltage 1 - max

50 Hz

Frequency control voltage 1 - min

50 Hz

Heat dissipation per pole, current-dependent

1.5 W

Incandescent lamp load - max

1980 W

Load fluorescent lamp - max

1020 VA

Load fluorescent lamp (duo circuit) - max

1820 VA

Load fluorescent lamp (parallel compensated) - max

1105 VA

Number of contacts (change-over contacts)

0

Number of contacts (normally closed contacts)

1

Number of contacts (normally open contacts)

1

Rated operational current for specified heat dissipation (In)

16 A

Rated switch current

16 A

Equipment heat dissipation, current-dependent

3 W

Supply voltage - max

250 V

Supply voltage - min

24 V

Switching current (cos phi = 0.6) - max

24 A

Width in number of modular spacings

1

Built-in depth

60 mm

Operating mode

Manual operation possible

Control voltage 2 type

DC

Voltage type

AC

Functions

Mechanical switch

Contact configuration

1 NO / 1 NC

Control voltage 1

24 V

Control voltage 2

12 V

Type of control voltage 1

AC

Type of control voltage 2

DC

Frequency control voltage 1

50 Hz

Frequency control voltage 2

50 Hz

Suitable for manual operation

Yes

Supply voltage

250 V

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

1

Country of origin

Romania

HS Code

8536.49
