Eaton ZE-1,0 Motor Protection Relay 0.6-1.0 A for DILEM

Eaton ZE-1,0 is a motor protection relay for the DILEM series contactor, with a current setting range of 0.6 to 1.0 A. It provides overload and differential trip protection and is rated for EEx-e motors. Auxiliary contacts include one normally open and one normally closed. Maximum rated operational voltage is 690 V.

Manufacturer part number (MPN)

ZE-1,0

EAN / GTIN

4015080143765

Sales unit

pcs

Package quantity

5 pcs

Eaton catalogue number

014376

Depth

52 mm

Height

65 mm

Width

45 mm

Weight

0.075 kg

Certifications

CSA; CSA Class No.: 3211-03; UL 508; VDE 0660; UL; IEC/EN 60947-5-1; UL File No.: E29184; IEC/EN 60947; CE; CSA-C22.2 No. 14; CSA File No.: 012528; IEC/EN 60947-4-1; UL Category Control No.: NKCR

Number of auxiliary contacts (change-over contacts)

0

Number of auxiliary contacts (normally closed contacts)

1

Number of auxiliary contacts (normally open contacts)

1

Number of contacts (normally closed contacts)

1

Number of contacts (normally open contacts)

1

Equipment heat dissipation, current-dependent Pvid

4.8 W

Heat dissipation per pole, current-dependent Pvid

1.6 W

Rated operational current for specified heat dissipation (In)

1 A

Conventional thermal current Ith of auxiliary contacts (1-pole, open)

6 A

Rated operational current (Ie) at AC-15, 120 V

1.5 A

Rated operational current (Ie) at AC-15, 220 V, 230 V, 240 V

1.5 A

Rated operational current (Ie) at AC-15, 380 V, 400 V, 415 V

0.7 A

Rated operational current (Ie) at AC-15, 500 V

0.5 A

Rated operational current (Ie) at DC-13, 110 V

0.4 A

Rated operational current (Ie) at DC-13, 220 V, 230 V

0.2 A

Rated operational current (Ie) at DC-13, 24 V

0.9 A

Rated operational current (Ie) at DC-13, 60 V

0.75 A

Rated operational voltage (Ue) - max

690 V

Safe isolation

300 V AC, Between auxiliary contacts and main contacts, According to EN 61140; 250 V AC, Between auxiliary contacts, According to EN 61140; 300 V AC, Between main circuits, According to EN 61140

Switching capacity (auxiliary contacts, general use)

0.6 A, 600V AC, (UL/CSA); 1.5 A, 240V AC, (UL/CSA)

Switching capacity (auxiliary contacts, pilot duty)

D300, AC operated (UL/CSA); R300, DC operated (UL/CSA)

Features

Reset pushbutton manual/auto; Phase-failure sensitivity (according to IEC/EN 60947, VDE 0660 Part 102); Test/off button; Trip-free release

Ambient operating temperature - max

50 °C

Ambient operating temperature - min

-25 °C

Ambient operating temperature (enclosed) - max

40 °C

Ambient operating temperature (enclosed) - min

-25 °C

Class

CLASS 10 A / IEC 60947-4-1, 8.2.1.5.1.1. c) 4 min

Climatic proofing

Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclic, to IEC 60068-2-30

Degree of protection

IP20; IP00

Mounting method

Direct attachment; Direct mounting

Overload release current setting - max

1 A

Overload release current setting - min

0.6 A

Overvoltage category

III

Pollution degree

3

Product category

ZE overload relays for mini contactor relays

Protection

Finger and back-of-hand proof, Protection against direct contact when actuated from front (EN 50274)

Rated impulse withstand voltage (Uimp)

6000 V AC; 4000 V (auxiliary and control circuits)

Shock resistance

10 g, Mechanical, Sinusoidal, Shock duration 10 ms

Suitable for

Branch circuits, (UL/CSA)

Temperature compensation

Continuous; ≤ 0.25 %/K, residual error for T > 40°

Short-circuit current rating (basic rating)

5 kA, SCCR (UL/CSA); 3 A, max. Fuse, SCCR (UL/CSA); 15 A, max. CB, CB for max. 480 V, SCCR (UL/CSA)

Short-circuit protection rating

4 A gG/gL, Fuse, Type “2” coordination; 20 A gG/gL, Fuse, Type “1” coordination; Max. 4 A gG/gL, Fuse, Auxiliary contacts; Information on Type "1" and Type"2" coordination applies to 100 kA and 690 V

Screw size

M3.5, Terminal screw

Screwdriver size

2, Terminal screw, Pozidriv screwdriver; 0.8 x 5.5 mm, Terminal screw, Standard screwdriver

Stripping length (control circuit cable)

8 mm

Stripping length (main cable)

8 mm

Terminal capacity (flexible with ferrule)

2 x (0.5 - 1.5) mm², Main cables; 1 x (0.5 - 1.5) mm², Control circuit cables; 1 x (0.5 - 1.5) mm², Main cables

Terminal capacity (solid)

1 x (0.75 - 2.5) mm², Main cables; 1 x (0.75 - 2.5) mm², Control circuit cables; 2 x (0.75 - 2.5) mm², Control circuit cables

Terminal capacity (solid/stranded AWG)

18 - 14, Main cables; 2 x (18 - 12), Control circuit cables

Number of auxiliary contacts as normally open contact

1

Number of auxiliary contacts as normally closed contact

1

Release class

CLASS 10

Type of electrical connection of main circuit

Screw connection

Max. rated operation voltage Ue

690 V

Adjustable current range

0.6–1 A

Reset function input

No

Reset function automatic

Yes

Reset function push-button

Yes

Country of origin

Germany

HS Code

8536.30
