Eaton Vertical Segregation for 2x IZMX16, Bottom
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton XPIX16CCB-B-06 vertical segregation kit for two IZMX16 breakers, bottom-side installation. Steel individual part, 1268 x 65 x 502 mm, powder-coated grey (RAL 7035) to support internal separation forms 2a to 4b.
Technical Specifications
- Manufacturer part number (MPN)
- XPIX16CCB-B-06
- EAN / GTIN
- 4015081710225
- Sales unit
- pcs
- Eaton catalogue number
- 174567
- Depth
- 502 mm
- Height
- 1268 mm
- Width
- 65 mm
- Weight
- 13.09 kg
- Compliances
- RoHS conform
- RAL-number
- 7035
- Suitable for
- Internal separation form 3b; Internal separation form 4b; Internal separation form 4a; Internal separation form 2b; Internal separation form 3a; Internal separation form 2a
- Color
- Gray
- Construction type
- Individual part
- Material
- Steel
- Modular spacing
- 12.5 mm
- Number of height units
- 0
- Suitable for enclosure building length/depth
- 600 mm
- Suitable for enclosure building width
- 65 mm
- Surface finishing
- Powder coating
- Suitable for enclosure building depth
- 600 mm
- Colour
- Grey
- With cable entry
- No
- With lock
- No
- For internal separation form 2a
- Yes
- For internal separation form 2b
- Yes
- For internal separation form 3a
- Yes
- For internal separation form 3b
- Yes
- For internal separation form 4a
- Yes
- For internal separation form 4b
- Yes
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015081710225
- SAP 1200601607
- Code 82989114
Product Documentation
More from Eaton
Eaton
DG1 variable-frequency drive 400V: 90kW (DG1-34170FB-C54C)
Eaton
S.sk.terminal for CU20X5 (K20X15/40)
Eaton
Eaton Reversing Starter, Spring Clamp Connection (MSC-R-12-M12(230V50HZ)-PI)
Eaton
Shield clamp 1600A 4-pole xE Main
XBSB164
Eaton
Enclosure H×W×D=296X234X150MM (CI23-125-NA)
Eaton
K.el.Darw F.m with Red led 1NO/NC
M22-SWD-K11LED-R
Eaton
Mechanical interlock DILMT65-XMV
Eaton
K.el.Darw F.m m/Gr.led 2NO/NC
M22-SWD-K22LED-G
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XPIX16CCB-B-06?
- XPIX16CCB-B-06 can be ordered from cballast.com as a Eaton catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Eaton product?
- The manufacturer part number is XPIX16CCB-B-06.
- What is the HS code for XPIX16CCB-B-06?
- The customs tariff (HS) code for XPIX16CCB-B-06 is 8538.90.
- Who manufactures XPIX16CCB-B-06?
- XPIX16CCB-B-06 is a Eaton product in the Enclosures range.
- Is a datasheet available for XPIX16CCB-B-06?
- Yes — the XPIX16CCB-B-06 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XPIX16CCB-B-06?
- The minimum order quantity is 1.
- Is XPIX16CCB-B-06 available?
- Yes — XPIX16CCB-B-06 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
