Eaton KT-M32 Diaphragm Cable Grommet M32 IP66 Light Grey

Eaton KT-M32 is a metric diaphragm cable grommet with an integral push-through diaphragm, sized M32 for outer cable diameters from 1 to 25 mm and wall thicknesses of 1 to 9.5 mm. The polyethylene grommet is gastight, watertight and halogen-free, achieving IP66 at pollution degree 3 and overvoltage category III. Suitable for H03VV-F 0.75 mm² (3 cables), NYM 16 mm² (4 cables) or 10 mm² (5 cables). Finish RAL 7035 light grey; supplied in packs of 100. Eaton catalogue number 207604.

Manufacturer part number (MPN)

KT-M32

EAN / GTIN

4015082076047

Sales unit

pcs

Package quantity

100 pcs

Eaton catalogue number

207604

Depth

20 mm

Height

35 mm

Width

35 mm

Weight

0.004 kg

Compliances

RoHS conform

Used with

H03VV-F 0.75 mm² (3x); NYM 16 mm² (4x) or 10 mm² (5x); Diaphragm grommets

Special features

With integral push-through diaphragm

Type

General switchboard accessory

Features

Gastight; Halogen free; Watertight

Thread size

M32

Stress fracture risk

Relative high

Bore diameter

32.5 mm

For outer cable diameter - max

25 mm

For outer cable diameter - min

1 mm

For wall thickness - max

9.5 mm

For wall thickness - min

1 mm

Number of cables - max

1

Number of cables - min

1

Opening diameter

32.5 mm

Operating temperature - max

40 °C

Operating temperature - min

-5 °C

Suitable for cable diameter - max

25 mm

Suitable for cable diameter - min

1 mm

Thread size (PG)

0

Pollution degree

3

Cable entry type

Round; M32

Surface finishing

RAL 7035, light gray

Color

Light gray (RAL 7035); Gray

Degree of protection

IP66

Surface protection

Other

Accessory/spare part type

Metric diaphragm grommets; Cable grommets; Cable management

Chemical resistance

Resistant against: alcohol, animal and plant fat, brine, light acids, water

Material quality

Polyethylene (PE)

Material

Other; Halogen free; PE and thermoplastic elastomer; Silicone free

Model

Closed

Overvoltage category

III

Temperature resistance

Temperature resistant: -40 °C - 80 °C, short-time up to approx. 100 °C

Colour

Grey

Watertight

Yes

Halogen free

Yes

Total length

20 mm

Cable entry

Round

With strain relief

No

Operating temperature

-5–40 °C

Angle model

No

Suitable for cable diameter

1–25 mm

For wall thickness

1–9.5 mm

Shrink technique

No

Number of cables

1

Suitable for cable gland

No

Gastight

Yes

Fire resistant

No

Country of origin

Germany

HS Code

3926.90

• EAN 4015082076047
• SAP 1000289460
• Code 81039110
